WebSocket: Komunikasi Real-time untuk IoT

# === Client mengirim HTTP Upgrade Request ===
GET /ws/sensor HTTP/1.1
Host: 192.168.1.100:8080
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Version: 13
Origin: http://dashboard.local

# === Server membalas dengan 101 Switching Protocols ===
HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=

# === Setelah ini, komunikasi dalam format WebSocket frame ===
# Client → Server: {"cmd": "subscribe", "topic": "suhu"}
# Server → Client: {"suhu": 28.5, "kelembaban": 65}

// esp32_ws_client.ino — ESP32 WebSocket Client
// BeebaneLabs - https://beebanelabs.pages.dev

#include <WiFi.h>
#include <WebSocketsClient.h>
#include <DHT.h>

// === Konfigurasi WiFi ===
const char* ssid = "WiFi-Rumah";
const char* password = "password123";

// === Konfigurasi WebSocket Server ===
const char* ws_host = "192.168.1.100";
const uint16_t ws_port = 8080;
const char* ws_path = "/ws/sensor";

// === Pin Sensor ===
#define DHT_PIN 4
#define DHT_TYPE DHT22

WebSocketsClient webSocket;
DHT dht(DHT_PIN, DHT_TYPE);

// Callback saat event WebSocket terjadi
void webSocketEvent(WStype_t type, uint8_t* payload, size_t length) {
  switch (type) {
    case WStype_CONNECTED:
      Serial.println("[WS] Terhubung ke server!");
      // Kirim pesan identifikasi
      webSocket.sendTXT("{\"device\":\"esp32-001\",\"type\":\"sensor_node\"}");
      break;

    case WStype_DISCONNECTED:
      Serial.println("[WS] Terputus dari server!");
      break;

    case WStype_TEXT:
      Serial.printf("[WS] Pesan dari server: %s\n", payload);
      // Proses perintah dari server
      handleServerCommand((char*)payload);
      break;

    case WStype_ERROR:
      Serial.printf("[WS] Error: %s\n", payload);
      break;
  }
}

void handleServerCommand(String cmd) {
  // Contoh: server mengirim perintah kontrol LED
  if (cmd.indexOf("\"led\":\"on\"") >= 0) {
    digitalWrite(LED_BUILTIN, HIGH);
    webSocket.sendTXT("{\"status\":\"led_on\"}");
  } else if (cmd.indexOf("\"led\":\"off\"") >= 0) {
    digitalWrite(LED_BUILTIN, LOW);
    webSocket.sendTXT("{\"status\":\"led_off\"}");
  }
}

void setup() {
  Serial.begin(115200);
  pinMode(LED_BUILTIN, OUTPUT);
  dht.begin();

  // Koneksi WiFi
  WiFi.begin(ssid, password);
  Serial.print("Menghubungkan WiFi");
  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }
  Serial.println("\nWiFi terhubung!");
  Serial.println(WiFi.localIP());

  // Inisialisasi WebSocket
  webSocket.begin(ws_host, ws_port, ws_path);
  webSocket.onEvent(webSocketEvent);
  webSocket.setReconnectInterval(5000);  // Reconnect setiap 5 detik
}

void loop() {
  webSocket.loop();

  // Kirim data sensor setiap 2 detik
  static unsigned long lastSend = 0;
  if (millis() - lastSend >= 2000) {
    lastSend = millis();

    float suhu = dht.readTemperature();
    float kelembaban = dht.readHumidity();

    if (!isnan(suhu) && !isnan(kelembaban)) {
      // Format JSON
      String json = "{\"device\":\"esp32-001\",";
      json += "\"suhu\":" + String(suhu, 1) + ",";
      json += "\"kelembaban\":" + String(kelembaban, 1) + ",";
      json += "\"uptime\":" + String(millis() / 1000) + "}";

      webSocket.sendTXT(json);
      Serial.println("[DATA] Terkirim: " + json);
    }
  }
}

// esp32_ws_server.ino — ESP32 sebagai WebSocket Server
// BeebaneLabs - https://beebanelabs.pages.dev

#include <WiFi.h>
#include <WebSocketsServer.h>

const char* ssid = "WiFi-Rumah";
const char* password = "password123";

WebSocketsServer webSocketServer = WebSocketsServer(81);

void webSocketEvent(uint8_t num, WStype_t type, uint8_t* payload, size_t length) {
  switch (type) {
    case WStype_CONNECTED: {
      IPAddress ip = webSocketServer.remoteIP(num);
      Serial.printf("[WS] Client #%d terhubung dari %s\n", num, ip.toString().c_str());
      // Kirim pesan selamat datang
      webSocketServer.sendTXT(num, "{\"msg\":\"Terhubung ke ESP32!\"}");
      break;
    }
    case WStype_TEXT:
      Serial.printf("[WS] Client #%d: %s\n", num, payload);
      // Echo kembali ke semua client
      webSocketServer.broadcastTXT(payload);
      break;
    case WStype_DISCONNECTED:
      Serial.printf("[WS] Client #%d terputus\n", num);
      break;
  }
}

void setup() {
  Serial.begin(115200);
  WiFi.begin(ssid, password);
  while (WiFi.status() != WL_CONNECTED) { delay(500); }
  Serial.printf("IP ESP32: %s\n", WiFi.localIP().toString().c_str());

  webSocketServer.begin();
  webSocketServer.onEvent(webSocketEvent);
}

void loop() {
  webSocketServer.loop();

  // Broadcast data sensor ke semua client setiap 3 detik
  static unsigned long lastBroadcast = 0;
  if (millis() - lastBroadcast >= 3000) {
    lastBroadcast = millis();
    float suhu = random(250, 350) / 10.0;
    String data = "{\"suhu\":" + String(suhu) + ",\"source\":\"esp32-server\"}";
    webSocketServer.broadcastTXT(data);
  }
}

# Buat project baru
mkdir ws-iot-server && cd ws-iot-server
npm init -y

# Instal library WebSocket dan Express
npm install ws express

# (Opsional) Instal untuk development
npm install -D nodemon

// server.js — WebSocket Server untuk IoT
// BeebaneLabs - https://beebanelabs.pages.dev

const WebSocket = require('ws');
const http = require('http');
const express = require('express');

const app = express();
const server = http.createServer(app);
const wss = new WebSocket.Server({ server, path: '/ws/sensor' });

// Simpan koneksi client
const clients = new Map();

wss.on('connection', (ws, req) => {
  const clientId = Date.now().toString(36);
  const clientIP = req.socket.remoteAddress;
  console.log(`[WS] Client terhubung: ${clientId} dari ${clientIP}`);

  // Simpan client
  clients.set(clientId, {
    ws: ws,
    connectedAt: new Date(),
    device: null
  });

  // Kirim pesan selamat datang
  ws.send(JSON.stringify({
    type: 'welcome',
    clientId: clientId,
    msg: 'Terhubung ke BeebaneLabs IoT Server'
  }));

  // Handle pesan masuk
  ws.on('message', (data) => {
    try {
      const msg = JSON.parse(data);
      console.log(`[DATA] dari ${clientId}:`, msg);

      // Identifikasi perangkat
      if (msg.device) {
        clients.get(clientId).device = msg.device;
      }

      // Broadcast ke semua client lain
      broadcast(clientId, msg);

    } catch (e) {
      console.error('[ERROR] Pesan tidak valid:', e.message);
    }
  });

  // Handle disconnect
  ws.on('close', () => {
    const client = clients.get(clientId);
    console.log(`[WS] Client terputus: ${client?.device || clientId}`);
    clients.delete(clientId);
  });

  // Handle error
  ws.on('error', (err) => {
    console.error(`[ERROR] Client ${clientId}:`, err.message);
  });
});

// Fungsi broadcast ke semua client kecuali pengirim
function broadcast(senderId, data) {
  const message = JSON.stringify(data);
  clients.forEach((client, id) => {
    if (id !== senderId && client.ws.readyState === WebSocket.OPEN) {
      client.ws.send(message);
    }
  });
}

// REST endpoint untuk status
app.get('/api/status', (req, res) => {
  res.json({
    connectedClients: clients.size,
    uptime: process.uptime(),
    devices: Array.from(clients.values()).map(c => c.device).filter(Boolean)
  });
});

// Mulai server
const PORT = process.env.PORT || 8080;
server.listen(PORT, () => {
  console.log(`[SERVER] WebSocket server berjalan di port ${PORT}`);
  console.log(`[SERVER] WebSocket endpoint: ws://localhost:${PORT}/ws/sensor`);
});

// === Pola Broadcasting ===

// 1. Broadcast ke SEMUA client (termasuk pengirim)
function broadcastAll(data) {
  const message = JSON.stringify(data);
  wss.clients.forEach((client) => {
    if (client.readyState === WebSocket.OPEN) {
      client.send(message);
    }
  });
}

// 2. Broadcast ke semua KECUALI pengirim
function broadcastExcept(sender, data) {
  const message = JSON.stringify(data);
  wss.clients.forEach((client) => {
    if (client !== sender && client.readyState === WebSocket.OPEN) {
      client.send(message);
    }
  });
}

// 3. Broadcast berdasarkan ROOM (grup topik)
const rooms = new Map();

function joinRoom(clientId, roomName) {
  if (!rooms.has(roomName)) rooms.set(roomName, new Set());
  rooms.get(roomName).add(clientId);
}

function broadcastToRoom(roomName, data) {
  const room = rooms.get(roomName);
  if (!room) return;
  const message = JSON.stringify(data);
  room.forEach((clientId) => {
    const client = clients.get(clientId);
    if (client?.ws.readyState === WebSocket.OPEN) {
      client.ws.send(message);
    }
  });
}

// Contoh penggunaan room:
// Client mengirim: {"action": "join", "room": "ruang_tamu"}
// Server menjalankan: joinRoom(clientId, "ruang_tamu")
// Broadcast ke room: broadcastToRoom("ruang_tamu", sensorData)

// browser-ws.js — Client WebSocket di browser
// BeebaneLabs - https://beebanelabs.pages.dev

const wsUrl = 'ws://192.168.1.100:8080/ws/sensor';
let ws = null;

function connectWebSocket() {
  ws = new WebSocket(wsUrl);

  ws.onopen = () => {
    console.log('Terhubung ke WebSocket server');
    document.getElementById('status').textContent = '🟢 Connected';
    // Subscribe ke topik tertentu
    ws.send(JSON.stringify({
      action: 'subscribe',
      topics: ['suhu', 'kelembaban']
    }));
  };

  ws.onmessage = (event) => {
    const data = JSON.parse(event.data);
    console.log('Data diterima:', data);

    // Update dashboard
    if (data.suhu !== undefined) {
      document.getElementById('suhu').textContent = data.suhu + ' °C';
    }
    if (data.kelembaban !== undefined) {
      document.getElementById('kelembaban').textContent = data.kelembaban + ' %';
    }
  };

  ws.onclose = () => {
    console.log('Koneksi terputus, reconnect dalam 3 detik...');
    document.getElementById('status').textContent = '🔴 Disconnected';
    setTimeout(connectWebSocket, 3000);  // Auto reconnect
  };

  ws.onerror = (err) => {
    console.error('WebSocket error:', err);
  };
}

connectWebSocket();

// autentikasi.js — Autentikasi WebSocket dengan JWT
const jwt = require('jsonwebtoken');
const SECRET_KEY = 'rahasia-jangan-dibagikan';

// Saat upgrade connection
wss.on('connection', (ws, req) => {
  // Ambil token dari query parameter
  const url = new URL(req.url, 'http://localhost');
  const token = url.searchParams.get('token');

  if (!token) {
    ws.close(4001, 'Token tidak ditemukan');
    return;
  }

  try {
    const decoded = jwt.verify(token, SECRET_KEY);
    ws.user = decoded;  // Simpan info user
    console.log(`[AUTH] User ${decoded.username} terotentikasi`);

    // Lanjutkan proses normal...
    ws.send(JSON.stringify({ type: 'auth_ok', user: decoded.username }));

  } catch (err) {
    ws.close(4003, 'Token tidak valid atau expired');
    return;
  }
});

// Client terhubung dengan token:
// ws://server:8080/ws?token=eyJhbGciOiJIUzI1NiIs...

// Saat HTTP upgrade request
server.on('upgrade', (request, socket, head) => {
  // Ambil cookie dari header
  const cookies = parseCookies(request.headers.cookie);
  const sessionToken = cookies['session_token'];

  if (!sessionToken || !validateSession(sessionToken)) {
    socket.write('HTTP/1.1 401 Unauthorized\r\n\r\n');
    socket.destroy();
    return;
  }

  // Lolos autentikasi, lanjutkan upgrade ke WebSocket
  wss.handleUpgrade(request, socket, head, (ws) => {
    ws.user = getUserFromSession(sessionToken);
    wss.emit('connection', ws, request);
  });
});

function parseCookies(cookieHeader) {
  const cookies = {};
  if (!cookieHeader) return cookies;
  cookieHeader.split(';').forEach(cookie => {
    const [name, value] = cookie.trim().split('=');
    cookies[name] = decodeURIComponent(value);
  });
  return cookies;
}

// scaled-server.js — Multi-instance WebSocket dengan Redis
const Redis = require('ioredis');
const WebSocket = require('ws');

// Dua koneksi Redis: satu subscribe, satu publish
const redisSub = new Redis({ host: 'redis-server', port: 6379 });
const redisPub = new Redis({ host: 'redis-server', port: 6379 });

const wss = new WebSocket.Server({ port: 8080 });

// Subscribe ke channel Redis
redisSub.subscribe('iot-broadcast');
redisSub.on('message', (channel, message) => {
  // Terima pesan dari server lain, kirim ke local clients
  wss.clients.forEach((client) => {
    if (client.readyState === WebSocket.OPEN) {
      client.send(message);
    }
  });
});

wss.on('connection', (ws) => {
  ws.on('message', (data) => {
    // Publish ke Redis agar server lain juga menerima
    redisPub.publish('iot-broadcast', data.toString());
  });
});

// Jalankan beberapa instance:
// PORT=8080 node scaled-server.js  (instance 1)
// PORT=8081 node scaled-server.js  (instance 2)
// Load balancer (nginx) mendistribusikan koneksi

# /etc/nginx/sites-available/ws-iot
upstream ws_backend {
    # Load balancing antar beberapa instance
    server 127.0.0.1:8080;
    server 127.0.0.1:8081;
    server 127.0.0.1:8082;
}

server {
    listen 443 ssl;
    server_name iot.example.com;

    ssl_certificate /etc/ssl/certs/iot.pem;
    ssl_certificate_key /etc/ssl/private/iot.key;

    location /ws/ {
        proxy_pass http://ws_backend;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection "upgrade";
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_read_timeout 86400;  # 24 jam
        proxy_send_timeout 86400;
    }
}

<!DOCTYPE html>
<html lang="id">
<head>
  <meta charset="UTF-8">
  <title>IoT Dashboard Real-time</title>
  <script src="https://cdn.jsdelivr.net/npm/chart.js"></script>
  <style>
    body { font-family: Arial, sans-serif; background: #1a1a2e; color: #eee; }
    .cards { display: flex; gap: 20px; margin: 20px; flex-wrap: wrap; }
    .card {
      background: #16213e; border-radius: 12px; padding: 20px;
      flex: 1; min-width: 200px; text-align: center;
    }
    .card h2 { font-size: 2.5em; margin: 0; }
    .card .label { color: #888; }
    .chart-container { margin: 20px; background: #16213e; border-radius: 12px; padding: 20px; }
    .status { padding: 8px 16px; border-radius: 20px; font-size: 0.9em; }
    .status.online { background: #22c55e33; color: #22c55e; }
    .status.offline { background: #ef444433; color: #ef4444; }
  </style>
</head>
<body>
  <h1 style="margin:20px">🌡️ IoT Real-time Dashboard</h1>
  <div>
    Status: <span id="status" class="status offline">🔴 Terputus</span>
  </div>

  <div class="cards">
    <div class="card">
      <div class="label">Suhu</div>
      <h2 id="suhu">--</h2>
      <div>°C</div>
    </div>
    <div class="card">
      <div class="label">Kelembaban</h2>
      <h2 id="kelembaban">--</h2>
      <div>%</div>
    </div>
    <div class="card">
      <div class="label">Uptime</div>
      <h2 id="uptime">--</h2>
      <div>detik</div>
    </div>
  </div>

  <div class="chart-container">
    <canvas id="chart" height="100"></canvas>
  </div>

  <script>
    // Inisialisasi chart
    const ctx = document.getElementById('chart').getContext('2d');
    const maxDataPoints = 50;
    const chart = new Chart(ctx, {
      type: 'line',
      data: {
        labels: [],
        datasets: [{
          label: 'Suhu (°C)',
          data: [],
          borderColor: '#ef4444',
          tension: 0.3,
          fill: false
        }, {
          label: 'Kelembaban (%)',
          data: [],
          borderColor: '#3b82f6',
          tension: 0.3,
          fill: false
        }]
      },
      options: {
        responsive: true,
        scales: {
          x: { ticks: { color: '#888' } },
          y: { ticks: { color: '#888' } }
        },
        plugins: { legend: { labels: { color: '#eee' } } }
      }
    });

    // WebSocket connection
    const ws = new WebSocket('ws://192.168.1.100:8080/ws/sensor');

    ws.onopen = () => {
      document.getElementById('status').textContent = '🟢 Terhubung';
      document.getElementById('status').className = 'status online';
    };

    ws.onmessage = (event) => {
      const data = JSON.parse(event.data);
      const time = new Date().toLocaleTimeString('id-ID');

      // Update cards
      if (data.suhu) document.getElementById('suhu').textContent = data.suhu;
      if (data.kelembaban) document.getElementById('kelembaban').textContent = data.kelembaban;
      if (data.uptime) document.getElementById('uptime').textContent = data.uptime;

      // Update chart
      chart.data.labels.push(time);
      chart.data.datasets[0].data.push(data.suhu);
      chart.data.datasets[1].data.push(data.kelembaban);

      // Batasi jumlah data points
      if (chart.data.labels.length > maxDataPoints) {
        chart.data.labels.shift();
        chart.data.datasets[0].data.shift();
        chart.data.datasets[1].data.shift();
      }
      chart.update();
    };

    ws.onclose = () => {
      document.getElementById('status').textContent = '🔴 Terputus';
      document.getElementById('status').className = 'status offline';
      setTimeout(() => location.reload(), 3000);
    };
  </script>
</body>
</html>
