Python Excel: openpyxl & pandas

Formula yang Sering Digunakan

7. Membuat Chart

openpyxl mendukung pembuatan berbagai jenis chart langsung di Excel, termasuk bar chart, line chart, pie chart, dan scatter chart.

"""Membuat berbagai chart di Excel."""
from openpyxl import Workbook
from openpyxl.chart import BarChart, LineChart, PieChart, Reference
from openpyxl.chart.series import DataPoint
from openpyxl.chart.label import DataLabelList
from openpyxl.styles import Font, Alignment

wb = Workbook()

# ==========================================
# Sheet 1: Bar Chart — Penjualan per Produk
# ==========================================
ws1 = wb.active
ws1.title = "Bar Chart"

# Data
ws1.append(["Produk", "Q1", "Q2", "Q3", "Q4"])
ws1.append(["Laptop", 150, 180, 200, 220])
ws1.append(["Desktop", 100, 90, 85, 80])
ws1.append(["Monitor", 80, 100, 120, 140])
ws1.append(["Keyboard", 200, 210, 190, 230])
ws1.append(["Mouse", 300, 320, 310, 350])

# Membuat Bar Chart
bar_chart = BarChart()
bar_chart.type = "col"  # "col" = vertikal, "bar" = horizontal
bar_chart.title = "Penjualan per Produk (Unit)"
bar_chart.y_axis.title = "Jumlah Unit"
bar_chart.x_axis.title = "Produk"
bar_chart.style = 10  # Style 1-48

# Data reference
categories = Reference(ws1, min_col=1, min_row=2, max_row=6)
data = Reference(ws1, min_col=2, max_col=5, min_row=1, max_row=6)

bar_chart.add_data(data, titles_from_data=True)
bar_chart.set_categories(categories)
bar_chart.shape = 4
bar_chart.width = 20
bar_chart.height = 12

ws1.add_chart(bar_chart, "A9")

# ==========================================
# Sheet 2: Line Chart — Trend Bulanan
# ==========================================
ws2 = wb.create_sheet("Line Chart")

ws2.append(["Bulan", "Pendapatan", "Pengeluaran", "Profit"])
revenue_data = [
    ["Jan", 50, 30, 20], ["Feb", 55, 32, 23], ["Mar", 48, 28, 20],
    ["Apr", 62, 35, 27], ["Mei", 70, 38, 32], ["Jun", 75, 40, 35],
    ["Jul", 68, 37, 31], ["Agu", 72, 39, 33], ["Sep", 80, 42, 38],
    ["Okt", 85, 45, 40], ["Nov", 90, 48, 42], ["Des", 95, 50, 45],
]
for row in revenue_data:
    ws2.append(row)

# Line Chart
line_chart = LineChart()
line_chart.title = "Trend Pendapatan & Pengeluaran 2026 (Jutaan Rp)"
line_chart.y_axis.title = "Jutaan Rupiah"
line_chart.x_axis.title = "Bulan"
line_chart.style = 10
line_chart.width = 22
line_chart.height = 14

cats = Reference(ws2, min_col=1, min_row=2, max_row=13)
values = Reference(ws2, min_col=2, max_col=4, min_row=1, max_row=13)

line_chart.add_data(values, titles_from_data=True)
line_chart.set_categories(cats)

# Style lines
line_chart.series[0].graphicalProperties.line.width = 28000  # Width in EMUs
line_chart.series[1].graphicalProperties.line.width = 28000
line_chart.series[2].graphicalProperties.line.width = 28000

ws2.add_chart(line_chart, "A16")

# ==========================================
# Sheet 3: Pie Chart — Market Share
# ==========================================
ws3 = wb.create_sheet("Pie Chart")

ws3.append(["Brand", "Market Share (%)"])
ws3.append(["ASUS", 28])
ws3.append(["Lenovo", 22])
ws3.append(["HP", 18])
ws3.append(["Dell", 15])
ws3.append(["Acer", 10])
ws3.append(["Lainnya", 7])

pie_chart = PieChart()
pie_chart.title = "Market Share Laptop Indonesia 2026"
pie_chart.style = 10
pie_chart.width = 16
pie_chart.height = 12

labels = Reference(ws3, min_col=1, min_row=2, max_row=7)
data_ref = Reference(ws3, min_col=2, min_row=1, max_row=7)

pie_chart.add_data(data_ref, titles_from_data=True)
pie_chart.set_categories(labels)

# Data labels
pie_chart.dataLabels = DataLabelList()
pie_chart.dataLabels.showPercent = True
pie_chart.dataLabels.showCatName = True
pie_chart.dataLabels.showVal = False

ws3.add_chart(pie_chart, "A10")

# ==========================================
# Sheet 4: Combo Chart — Bar + Line
# ==========================================
ws4 = wb.create_sheet("Combo Chart")

ws4.append(["Tahun", "Pendapatan (M)", "Growth (%)"])
ws4.append([2020, 100, None])
ws4.append([2021, 120, 20])
ws4.append([2022, 145, 20.8])
ws4.append([2023, 170, 17.2])
ws4.append([2024, 210, 23.5])
ws4.append([2025, 250, 19.0])
ws4.append([2026, 300, 20.0])

from openpyxl.chart import BarChart, LineChart

# Bar chart untuk pendapatan
combo_bar = BarChart()
combo_bar.type = "col"
combo_bar.title = "Pendapatan & Growth Tahunan"
combo_bar.y_axis.title = "Pendapatan (Miliar Rp)"
combo_bar.style = 10
combo_bar.width = 18
combo_bar.height = 12

bar_data = Reference(ws4, min_col=2, min_row=1, max_row=8)
bar_cats = Reference(ws4, min_col=1, min_row=2, max_row=8)
combo_bar.add_data(bar_data, titles_from_data=True)
combo_bar.set_categories(bar_cats)

# Line chart untuk growth
combo_line = LineChart()
line_data = Reference(ws4, min_col=3, min_row=1, max_row=8)
combo_line.add_data(line_data, titles_from_data=True)
combo_line.y_axis.title = "Growth (%)"
combo_line.y_axis.axId = 200

# Gabungkan
combo_bar.y_axis.crosses = "min"
combo_bar += combo_line

ws4.add_chart(combo_bar, "A11")

# Simpan
wb.save("charts_example.xlsx")
print("✅ Contoh chart Excel berhasil dibuat!")

8. pandas: Read/Write Excel

pandas adalah library analisis data yang sangat powerful. pandas menggunakan openpyxl (atau xlrd untuk .xls) sebagai backend untuk membaca dan menulis file Excel.

Membaca Excel dengan pandas

"""Membaca file Excel menggunakan pandas."""
import pandas as pd

# === Membaca Sheet Default ===
df = pd.read_excel("employees.xlsx", sheet_name="Laporan")
print(f"Shape: {df.shape}")  # (baris, kolom)
print(f"Columns: {list(df.columns)}")
print(f"\n{df.head()}")

# === Membaca Sheet Spesifik ===
df = pd.read_excel("employees.xlsx", sheet_name="Laporan", usecols="A:D")
print(df.head())

# === Membaca dengan Filter Baris ===
# Hanya baca baris tertentu
df = pd.read_excel(
    "employees.xlsx",
    sheet_name="Laporan",
    skiprows=1,      # Skip 1 baris pertama
    nrows=5,         # Ambil 5 baris
)
print(df.head())

# === Membaca Semua Sheet ===
all_sheets = pd.read_excel(
    "employees.xlsx",
    sheet_name=None,  # None = semua sheet
    engine="openpyxl",
)
for name, sheet_df in all_sheets.items():
    print(f"\n📄 Sheet '{name}': {sheet_df.shape}")

# === Membaca dengan Tipe Data Spesifik ===
df = pd.read_excel(
    "employees.xlsx",
    dtype={
        "ID": "int64",
        "Nama": "str",
        "Gaji": "float64",
    },
    parse_dates=["Tanggal Masuk"],  # Auto-parse tanggal
)

Menulis Excel dengan pandas

"""Menulis DataFrame ke file Excel menggunakan pandas."""
import pandas as pd
import numpy as np
from datetime import datetime

# === Membuat DataFrame Contoh ===
np.random.seed(42)
df = pd.DataFrame({
    "Tanggal": pd.date_range("2026-01-01", periods=100, freq="D"),
    "Produk": np.random.choice(["Laptop", "Mouse", "Keyboard", "Monitor"], 100),
    "Kategori": np.random.choice(["Elektronik", "Aksesoris"], 100),
    "Qty": np.random.randint(1, 50, 100),
    "Harga": np.random.choice([25000000, 850000, 500000, 4500000], 100),
})
df["Total"] = df["Qty"] * df["Harga"]

# === Menulis ke Excel ===
# Cara dasar
df.to_excel("output_pandas.xlsx", index=False, sheet_name="Data")

# === Menulis dengan Formatting ===
with pd.ExcelWriter("output_styled.xlsx", engine="openpyxl") as writer:
    # Sheet 1: Data lengkap
    df.to_excel(writer, sheet_name="Semua Data", index=False)

    # Sheet 2: Rekap per Produk
    rekap_produk = df.groupby("Produk").agg({
        "Qty": "sum",
        "Total": "sum",
    }).reset_index()
    rekap_produk.to_excel(writer, sheet_name="Rekap Produk", index=False)

    # Sheet 3: Rekap per Bulan
    df["Bulan"] = df["Tanggal"].dt.to_period("M")
    rekap_bulan = df.groupby("Bulan").agg({
        "Qty": "sum",
        "Total": "sum",
    }).reset_index()
    rekap_bulan["Bulan"] = rekap_bulan["Bulan"].astype(str)
    rekap_bulan.to_excel(writer, sheet_name="Rekap Bulanan", index=False)

    # Sheet 4: Summary
    summary = pd.DataFrame({
        "Metrik": ["Total Pendapatan", "Total Qty", "Rata-rata/Transaksi", "Jumlah Transaksi"],
        "Nilai": [
            f"Rp{df['Total'].sum():,.0f}",
            df["Qty"].sum(),
            f"Rp{df['Total'].mean():,.0f}",
            len(df),
        ],
    })
    summary.to_excel(writer, sheet_name="Summary", index=False)

print("✅ File output_styled.xlsx berhasil dibuat dengan 4 sheet!")

Formatting Excel dari pandas

"""Formatting Excel dari pandas menggunakan openpyxl engine."""
import pandas as pd
from openpyxl import load_workbook
from openpyxl.styles import Font, PatternFill, Alignment, Border, Side
from openpyxl.chart import BarChart, Reference

# Buat data
df = pd.DataFrame({
    "Departemen": ["Engineering", "Marketing", "Finance", "HR", "Operations"],
    "Karyawan": [25, 15, 10, 8, 20],
    "Budget (Jt)": [500, 300, 200, 150, 400],
    "Actual (Jt)": [480, 320, 190, 145, 380],
})
df["Utilisasi (%)"] = (df["Actual (Jt)"] / df["Budget (Jt)"] * 100).round(1)

# Tulis data dulu
df.to_excel("formatted_pandas.xlsx", index=False, sheet_name="Budget")

# Buka dan format
wb = load_workbook("formatted_pandas.xlsx")
ws = wb["Budget"]

# Format header
header_font = Font(bold=True, color="FFFFFF", size=12)
header_fill = PatternFill("solid", fgColor="2F5496")

for cell in ws[1]:
    cell.font = header_font
    cell.fill = header_fill
    cell.alignment = Alignment(horizontal="center")

# Format data cells
for row in ws.iter_rows(min_row=2, max_row=ws.max_row, min_col=1, max_col=ws.max_column):
    for cell in row:
        cell.border = Border(
            left=Side("thin"), right=Side("thin"),
            top=Side("thin"), bottom=Side("thin"),
        )
        if isinstance(cell.value, (int, float)):
            cell.alignment = Alignment(horizontal="right")

# Conditional formatting — manual coloring
green_fill = PatternFill("solid", fgColor="C6EFCE")
red_fill = PatternFill("solid", fgColor="FFC7CE")

for row in range(2, ws.max_row + 1):
    utilization = ws.cell(row=row, column=5).value
    if utilization and utilization > 100:
        ws.cell(row=row, column=5).fill = red_fill
    elif utilization:
        ws.cell(row=row, column=5).fill = green_fill

# Tambah chart
chart = BarChart()
chart.title = "Budget vs Actual (Jutaan Rp)"
chart.width = 18
chart.height = 10

cats = Reference(ws, min_col=1, min_row=2, max_row=6)
data = Reference(ws, min_col=3, max_col=4, min_row=1, max_row=6)
chart.add_data(data, titles_from_data=True)
chart.set_categories(cats)

ws.add_chart(chart, "A9")

# Auto-width columns
for col in range(1, 6):
    max_len = max(len(str(ws.cell(row=r, column=col).value or ""))
                  for r in range(1, ws.max_row + 1))
    ws.column_dimensions[chr(64 + col)].width = max_len + 4

wb.save("formatted_pandas.xlsx")
print("✅ Formatted pandas Excel berhasil dibuat!")

9. Multi-Sheet & Advanced

Append ke Sheet yang Sudah Ada

"""Append data ke Excel yang sudah ada."""
import pandas as pd
from openpyxl import load_workbook

def append_to_excel(filepath: str, new_data: pd.DataFrame, sheet_name: str = "Data"):
    """Append DataFrame ke sheet yang sudah ada."""
    try:
        # Baca data yang sudah ada
        existing = pd.read_excel(filepath, sheet_name=sheet_name)

        # Gabungkan
        combined = pd.concat([existing, new_data], ignore_index=True)

        # Tulis ulang
        with pd.ExcelWriter(filepath, engine="openpyxl", mode="a",
                           if_sheet_exists="replace") as writer:
            combined.to_excel(writer, sheet_name=sheet_name, index=False)

        print(f"✅ {len(new_data)} baris ditambahkan (total: {len(combined)})")
    except FileNotFoundError:
        new_data.to_excel(filepath, index=False, sheet_name=sheet_name)
        print(f"✅ File baru dibuat dengan {len(new_data)} baris")


# Contoh penggunaan
new_rows = pd.DataFrame({
    "Nama": ["User Baru 1", "User Baru 2"],
    "Departemen": ["IT", "Sales"],
    "Gaji": [15000000, 12000000],
})

append_to_excel("employees.xlsx", new_rows, "Laporan")

Merge Multiple Excel Files

"""Menggabungkan beberapa file Excel menjadi satu."""
import pandas as pd
from pathlib import Path


def merge_excel_files(input_dir: str, output_file: str, pattern: str = "*.xlsx"):
    """Gabungkan semua file Excel di direktori."""
    files = list(Path(input_dir).glob(pattern))
    all_data = []

    for file in files:
        try:
            df = pd.read_excel(file, engine="openpyxl")
            df["Source_File"] = file.name  # Track sumber data
            all_data.append(df)
            print(f"  📄 {file.name}: {len(df)} baris")
        except Exception as e:
            print(f"  ❌ Error reading {file.name}: {e}")

    if all_data:
        combined = pd.concat(all_data, ignore_index=True)
        combined.to_excel(output_file, index=False, sheet_name="Combined")
        print(f"\n✅ {len(combined)} baris dari {len(files)} file → {output_file}")
        return combined
    else:
        print("❌ Tidak ada data yang bisa digabungkan")
        return None


# Contoh penggunaan
# merge_excel_files("./data/", "merged_output.xlsx")

Excel dengan Data Validation

"""Menambahkan data validation (dropdown) di Excel."""
from openpyxl import Workbook
from openpyxl.worksheet.datavalidation import DataValidation
from openpyxl.styles import Font

wb = Workbook()
ws = wb.active
ws.title = "Form Input"

# Header
headers = ["Nama", "Departemen", "Status", "Prioritas", "Tanggal"]
for col, header in enumerate(headers, 1):
    ws.cell(row=1, column=col, value=header).font = Font(bold=True)

# Data Validation — Departemen (dropdown)
dept_dv = DataValidation(
    type="list",
    formula1='"Engineering,Marketing,Finance,HR,Operations"',
    allow_blank=True,
)
dept_dv.error = "Departemen tidak valid"
dept_dv.errorTitle = "Error"
dept_dv.prompt = "Pilih departemen"
dept_dv.promptTitle = "Departemen"
ws.add_data_validation(dept_dv)
dept_dv.add("B2:B100")

# Data Validation — Status (dropdown)
status_dv = DataValidation(
    type="list",
    formula1='"Active,Inactive,Pending"',
    allow_blank=True,
)
ws.add_data_validation(status_dv)
status_dv.add("C2:C100")

# Data Validation — Prioritas (dropdown)
priority_dv = DataValidation(
    type="list",
    formula1='"Low,Medium,High,Critical"',
    allow_blank=True,
)
ws.add_data_validation(priority_dv)
priority_dv.add("D2:D100")

# Data Validation — Tanggal
from datetime import date
date_dv = DataValidation(
    type="date",
    operator="greaterThan",
    formula1="2020-01-01",
    allow_blank=True,
)
ws.add_data_validation(date_dv)
date_dv.add("E2:E100")

# Data Validation — Nama (panjang teks)
name_dv = DataValidation(
    type="textLength",
    operator="lessThan",
    formula1="100",
)
name_dv.error = "Nama terlalu panjang (maks 100 karakter)"
ws.add_data_validation(name_dv)
name_dv.add("A2:A100")

# Column widths
for col in range(1, 6):
    ws.column_dimensions[chr(64 + col)].width = 18

wb.save("form_with_validation.xlsx")
print("✅ Form dengan data validation berhasil dibuat")

10. Otomasi Excel

Batch Processing — Generate Report Otomatis

"""Otomasi pembuatan laporan Excel dari data."""
import pandas as pd
from openpyxl import load_workbook
from openpyxl.styles import Font, PatternFill, Alignment, Border, Side
from datetime import datetime
import os


def generate_monthly_report(data_file: str, output_dir: str = "reports"):
    """Generate laporan bulanan dari data mentah."""

    # Baca data mentah
    df = pd.read_excel(data_file, engine="openpyxl")
    df["Tanggal"] = pd.to_datetime(df["Tanggal"])
    df["Bulan"] = df["Tanggal"].dt.strftime("%Y-%m")

    os.makedirs(output_dir, exist_ok=True)

    # Generate per bulan
    for bulan, group in df.groupby("Bulan"):
        output_file = os.path.join(output_dir, f"laporan_{bulan}.xlsx")

        with pd.ExcelWriter(output_file, engine="openpyxl") as writer:
            # Sheet 1: Detail Transaksi
            group.to_excel(writer, sheet_name="Detail", index=False)

            # Sheet 2: Rekap Produk
            rekap = group.groupby("Produk").agg({
                "Qty": "sum",
                "Total": ["sum", "count"],
            }).round(0)
            rekap.columns = ["Total Qty", "Jumlah Transaksi", "Total Revenue"]
            rekap.to_excel(writer, sheet_name="Rekap Produk")

            # Sheet 3: Harian
            daily = group.groupby(df["Tanggal"].dt.date).agg({
                "Total": "sum",
            }).round(0)
            daily.to_excel(writer, sheet_name="Harian")

        # Format output
        wb = load_workbook(output_file)
        for sheet_name in wb.sheetnames:
            ws = wb[sheet_name]
            # Header formatting
            for cell in ws[1]:
                cell.font = Font(bold=True, color="FFFFFF")
                cell.fill = PatternFill("solid", fgColor="2F5496")
            # Auto-width
            for col in range(1, ws.max_column + 1):
                max_len = max(len(str(ws.cell(row=r, column=col).value or ""))
                             for r in range(1, min(ws.max_row + 1, 20)))
                ws.column_dimensions[chr(64 + col)].width = min(max_len + 4, 40)

        wb.save(output_file)
        print(f"  ✅ {output_file} ({len(group)} transaksi)")


# Contoh penggunaan:
# generate_monthly_report("data_penjualan.xlsx")

Excel Converter — Format ke Format

"""Konversi antar format file."""
import pandas as pd


def convert_excel_to_csv(excel_file: str, sheet_name: str = None, output_csv: str = None):
    """Konversi Excel ke CSV."""
    df = pd.read_excel(excel_file, sheet_name=sheet_name, engine="openpyxl")
    if output_csv is None:
        output_csv = excel_file.replace(".xlsx", ".csv")
    df.to_csv(output_csv, index=False, encoding="utf-8-sig")  # BOM untuk Excel Indonesia
    print(f"✅ {excel_file} → {output_csv} ({len(df)} baris)")


def convert_csv_to_excel(csv_file: str, output_excel: str = None):
    """Konversi CSV ke Excel dengan formatting."""
    df = pd.read_csv(csv_file)
    if output_excel is None:
        output_excel = csv_file.replace(".csv", ".xlsx")
    df.to_excel(output_excel, index=False, sheet_name="Data")
    print(f"✅ {csv_file} → {output_excel} ({len(df)} baris)")


def convert_json_to_excel(json_file: str, output_excel: str = None):
    """Konversi JSON ke Excel."""
    df = pd.read_json(json_file)
    if output_excel is None:
        output_excel = json_file.replace(".json", ".xlsx")
    df.to_excel(output_excel, index=False, sheet_name="Data")
    print(f"✅ {json_file} → {output_excel} ({len(df)} baris)")


# Contoh
# convert_excel_to_csv("report.xlsx", "Sheet1")
# convert_csv_to_excel("data.csv")
# convert_json_to_excel("api_response.json")

11. Best Practice

Handling File Besar

"""Best practice untuk file Excel besar."""
import pandas as pd
from openpyxl import load_workbook
import gc


# === 1. Baca dalam Chunk ===
def read_large_excel_chunked(filepath: str, chunk_size: int = 10000):
    """Baca file besar dalam chunk."""
    total_rows = 0
    for chunk in pd.read_excel(
        filepath,
        sheet_name="Data",
        engine="openpyxl",
        chunksize=chunk_size,  # Untuk .csv, tidak untuk .xlsx
    ):
        total_rows += len(chunk)
        # Proses chunk di sini
        yield chunk

# NOTE: pd.read_excel() tidak support chunksize langsung.
# Gunakan openpyxl untuk streaming:
def stream_large_excel(filepath: str, batch_size: int = 1000):
    """Stream data dari file Excel besar menggunakan openpyxl."""
    wb = load_workbook(filepath, read_only=True, data_only=True)
    ws = wb.active

    headers = None
    batch = []

    for row_idx, row in enumerate(ws.iter_rows(values_only=True)):
        if row_idx == 0:
            headers = list(row)
            continue

        batch.append(dict(zip(headers, row)))

        if len(batch) >= batch_size:
            df = pd.DataFrame(batch)
            yield df
            batch = []
            gc.collect()

    # Sisa batch
    if batch:
        yield pd.DataFrame(batch)

    wb.close()


# Contoh penggunaan
# for chunk_df in stream_large_excel("big_file.xlsx", batch_size=5000):
#     # Proses per batch
#     result = chunk_df.groupby("Kategori")["Total"].sum()
#     print(result)


# === 2. Optimasi Memori ===
def optimize_excel_memory(df: pd.DataFrame) -> pd.DataFrame:
    """Optimasi tipe data DataFrame untuk menghemat memori."""
    for col in df.columns:
        col_type = df[col].dtype

        if col_type == "object":
            # Cek apakah bisa jadi category
            if df[col].nunique() / len(df) < 0.5:
                df[col] = df[col].astype("category")

        elif col_type == "int64":
            # Downcast integer
            df[col] = pd.to_numeric(df[col], downcast="integer")

        elif col_type == "float64":
            # Downcast float
            df[col] = pd.to_numeric(df[col], downcast="float")

    return df


# === 3. Error Handling ===
def safe_read_excel(filepath: str, **kwargs) -> pd.DataFrame:
    """Baca Excel dengan error handling."""
    try:
        df = pd.read_excel(filepath, engine="openpyxl", **kwargs)
        print(f"✅ Berhasil membaca {filepath}: {df.shape}")
        return df
    except FileNotFoundError:
        print(f"❌ File tidak ditemukan: {filepath}")
    except ValueError as e:
        print(f"❌ Error membaca {filepath}: {e}")
    except Exception as e:
        print(f"❌ Unexpected error: {e}")
    return pd.DataFrame()

Checklist Best Practice

12. Quiz Pemahaman

Uji pemahaman Anda tentang manipulasi Excel dengan Python:
