Prometheus & Grafana Advanced

# docker-compose-monitoring.yaml
version: '3.8'

services:
  prometheus:
    image: prom/prometheus:v2.53.0
    ports:
      - "9090:9090"
    volumes:
      - ./prometheus/prometheus.yml:/etc/prometheus/prometheus.yml
      - ./prometheus/rules:/etc/prometheus/rules
      - prometheus_data:/prometheus
    command:
      - '--config.file=/etc/prometheus/prometheus.yml'
      - '--storage.tsdb.path=/prometheus'
      - '--storage.tsdb.retention.time=30d'
      - '--web.enable-lifecycle'
    restart: unless-stopped

  alertmanager:
    image: prom/alertmanager:v0.27.0
    ports:
      - "9093:9093"
    volumes:
      - ./alertmanager/alertmanager.yml:/etc/alertmanager/alertmanager.yml
    command:
      - '--config.file=/etc/alertmanager/alertmanager.yml'
    restart: unless-stopped

  grafana:
    image: grafana/grafana:11.1.0
    ports:
      - "3000:3000"
    environment:
      - GF_SECURITY_ADMIN_USER=admin
      - GF_SECURITY_ADMIN_PASSWORD=admin123
      - GF_INSTALL_PLUGINS=grafana-clock-panel
    volumes:
      - grafana_data:/var/lib/grafana
      - ./grafana/provisioning:/etc/grafana/provisioning
    restart: unless-stopped

  node-exporter:
    image: prom/node-exporter:v1.8.1
    ports:
      - "9100:9100"
    volumes:
      - /proc:/host/proc:ro
      - /sys:/host/sys:ro
      - /:/rootfs:ro
    command:
      - '--path.procfs=/host/proc'
      - '--path.sysfs=/host/sys'
      - '--path.rootfs=/rootfs'
    restart: unless-stopped

  cadvisor:
    image: gcr.io/cadvisor/cadvisor:v0.49.1
    ports:
      - "8080:8080"
    volumes:
      - /:/rootfs:ro
      - /var/run:/var/run:ro
      - /sys:/sys:ro
      - /var/lib/docker:/var/lib/docker:ro
    restart: unless-stopped

volumes:
  prometheus_data:
  grafana_data:

# prometheus/prometheus.yml
global:
  scrape_interval: 15s         # Default scrape interval
  evaluation_interval: 15s     # Rules evaluation interval
  scrape_timeout: 10s          # Scrape timeout

# Alert Rules
rule_files:
  - /etc/prometheus/rules/*.yml

# Alertmanager Configuration
alerting:
  alertmanagers:
    - static_configs:
        - targets:
            - alertmanager:9093

# Scrape Configurations
scrape_configs:
  # Prometheus self-monitoring
  - job_name: 'prometheus'
    static_configs:
      - targets: ['localhost:9090']

  # Node Exporter (system metrics)
  - job_name: 'node-exporter'
    static_configs:
      - targets:
          - 'node-exporter:9100'
        labels:
          environment: 'production'

  # cAdvisor (container metrics)
  - job_name: 'cadvisor'
    static_configs:
      - targets:
          - 'cadvisor:8080'

  # Application metrics
  - job_name: 'my-app'
    metrics_path: '/metrics'
    scrape_interval: 10s
    static_configs:
      - targets:
          - 'app:8080'
        labels:
          app: 'myapp'
          environment: 'production'

  # MySQL Exporter
  - job_name: 'mysql'
    static_configs:
      - targets:
          - 'mysql-exporter:9104'

  # Redis Exporter
  - job_name: 'redis'
    static_configs:
      - targets:
          - 'redis-exporter:9121'

  # NGINX Exporter
  - job_name: 'nginx'
    static_configs:
      - targets:
          - 'nginx-exporter:9113'

# Tambah repository
helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
helm repo add grafana https://grafana.github.io/helm-charts
helm repo update

# Install kube-prometheus-stack (Prometheus + Grafana + Alertmanager + exporters)
helm install monitoring prometheus-community/kube-prometheus-stack \
  --namespace monitoring \
  --create-namespace \
  --set grafana.adminPassword=admin123 \
  --set prometheus.prometheusSpec.retention=30d \
  --set prometheus.prometheusSpec.storageSpec.volumeClaimTemplate.spec.resources.requests.storage=50Gi

# Verifikasi
kubectl get pods -n monitoring

# Akses Grafana
kubectl port-forward -n monitoring svc/monitoring-grafana 3000:80
# Buka http://localhost:3000 (admin/admin123)

# Akses Prometheus
kubectl port-forward -n monitoring svc/monitoring-kube-prometheus-prometheus 9090:9090

# Counter — selalu gunakan rate() atau increase()
# Total HTTP requests per detik (5 menit terakhir)
rate(http_requests_total[5m])

# Total request dalam 1 jam terakhir
increase(http_requests_total[1h])

# Gauge — langsung query
# Memory usage saat ini
node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes * 100

# CPU load average
node_load1

# Histogram — gunakan histogram_quantile()
# 95th percentile request duration
histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m]))

# 99th percentile
histogram_quantile(0.99, rate(http_request_duration_seconds_bucket[5m]))

# Average request duration
rate(http_request_duration_seconds_sum[5m]) / rate(http_request_duration_seconds_count[5m])

# app.py - Flask dengan Prometheus metrics
from flask import Flask, request
from prometheus_client import (
    Counter, Histogram, Gauge, Info,
    generate_latest, CONTENT_TYPE_LATEST
)
import time
import psutil

app = Flask(__name__)

# === METRIC DEFINITIONS ===

# Counter: total HTTP requests
http_requests_total = Counter(
    'http_requests_total',
    'Total HTTP requests',
    ['method', 'endpoint', 'status_code']
)

# Histogram: request duration
http_request_duration = Histogram(
    'http_request_duration_seconds',
    'HTTP request duration in seconds',
    ['method', 'endpoint'],
    buckets=[0.01, 0.05, 0.1, 0.25, 0.5, 1.0, 2.5, 5.0, 10.0]
)

# Gauge: active connections
active_connections = Gauge(
    'app_active_connections',
    'Number of active connections'
)

# Gauge: queue size
queue_size = Gauge(
    'app_queue_size',
    'Current queue size',
    ['queue_name']
)

# Info: app version
app_info = Info(
    'app',
    'Application information'
)
app_info.info({
    'version': '1.0.0',
    'language': 'python',
    'framework': 'flask'
})

# === MIDDLEWARE ===
@app.before_request
def before_request():
    request._start_time = time.time()
    active_connections.inc()

@app.after_request
def after_request(response):
    # Record request duration
    duration = time.time() - request._start_time
    http_request_duration.labels(
        method=request.method,
        endpoint=request.path
    ).observe(duration)

    # Increment request counter
    http_requests_total.labels(
        method=request.method,
        endpoint=request.path,
        status_code=response.status_code
    ).inc()

    active_connections.dec()
    return response

# === METRICS ENDPOINT ===
@app.route('/metrics')
def metrics():
    return generate_latest(), 200, {'Content-Type': CONTENT_TYPE_LATEST}

# === APPLICATION ROUTES ===
@app.route('/')
def index():
    return {'status': 'ok', 'version': '1.0.0'}

@app.route('/api/users')
def get_users():
    time.sleep(0.1)  # Simulate work
    return {'users': ['user1', 'user2', 'user3']}

@app.route('/api/orders')
def get_orders():
    queue_size.labels(queue_name='orders').set(42)
    return {'orders': []}

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=8080)

// server.js - Express dengan Prometheus metrics
const express = require('express');
const client = require('prom-client');

const app = express();
const PORT = 8080;

// === METRIC DEFINITIONS ===
const httpRequestsTotal = new client.Counter({
  name: 'http_requests_total',
  help: 'Total HTTP requests',
  labelNames: ['method', 'route', 'status']
});

const httpRequestDuration = new client.Histogram({
  name: 'http_request_duration_seconds',
  help: 'HTTP request duration in seconds',
  labelNames: ['method', 'route'],
  buckets: [0.01, 0.05, 0.1, 0.25, 0.5, 1.0, 2.5, 5.0]
});

const activeConnections = new client.Gauge({
  name: 'app_active_connections',
  help: 'Number of active connections'
});

const dbQueryDuration = new client.Histogram({
  name: 'db_query_duration_seconds',
  help: 'Database query duration',
  labelNames: ['query_type', 'table'],
  buckets: [0.001, 0.005, 0.01, 0.05, 0.1, 0.5, 1.0]
});

// Collect default metrics (CPU, memory, event loop lag)
client.collectDefaultMetrics({ prefix: 'nodejs_' });

// === MIDDLEWARE ===
app.use((req, res, next) => {
  const start = Date.now();
  activeConnections.inc();

  res.on('finish', () => {
    const duration = (Date.now() - start) / 1000;
    httpRequestsTotal.inc({
      method: req.method,
      route: req.path,
      status: res.statusCode
    });
    httpRequestDuration.observe(
      { method: req.method, route: req.path },
      duration
    );
    activeConnections.dec();
  });
  next();
});

// === METRICS ENDPOINT ===
app.get('/metrics', async (req, res) => {
  res.set('Content-Type', client.register.contentType);
  res.send(await client.register.metrics());
});

// === APPLICATION ROUTES ===
app.get('/', (req, res) => {
  res.json({ status: 'ok', version: '1.0.0' });
});

app.get('/api/users', (req, res) => {
  // Simulate DB query timing
  const end = dbQueryDuration.startTimer({ query_type: 'SELECT', table: 'users' });
  // ... query database ...
  end();
  res.json({ users: ['user1', 'user2'] });
});

app.listen(PORT, () => {
  console.log(`App running on port ${PORT}`);
});

# Jalankan node_exporter
docker run -d \
  --name node-exporter \
  --net=host \
  --pid=host \
  -v "/:/host:ro,rslave" \
  prom/node-exporter:v1.8.1 \
  --path.rootfs=/host

# Cek metrics
curl http://localhost:9100/metrics | head -50

# Contoh output:
# node_cpu_seconds_total{cpu="0",mode="idle"} 123456.78
# node_memory_MemTotal_bytes 8589934592
# node_filesystem_size_bytes{mountpoint="/"} 107374182400

# blackbox.yml - Konfigurasi blackbox exporter
modules:
  http_2xx:
    prober: http
    timeout: 5s
    http:
      valid_http_versions: ["HTTP/1.1", "HTTP/2.0"]
      valid_status_codes: [200]
      method: GET
      follow_redirects: true
      preferred_ip_protocol: "ip4"

  http_post_2xx:
    prober: http
    http:
      method: POST
      valid_status_codes: [200, 201]

  tcp_connect:
    prober: tcp
    timeout: 5s

  icmp:
    prober: icmp
    timeout: 5s

---
# prometheus.yml — scrape config untuk blackbox
scrape_configs:
  - job_name: 'blackbox-http'
    metrics_path: /probe
    params:
      module: [http_2xx]
    static_configs:
      - targets:
          - https://app.example.com
          - https://api.example.com
          - https://blog.example.com
    relabel_configs:
      - source_labels: [__address__]
        target_label: __param_target
      - source_labels: [__param_target]
        target_label: instance
      - target_label: __address__
        replacement: blackbox-exporter:9115

# rate() — perhitungan per-detik untuk counter (wajib untuk counter!)
rate(http_requests_total[5m])

# Per-second rate per status code
rate(http_requests_total{status_code="500"}[5m])

# increase() — total increase dalam periode
increase(http_requests_total[1h])

# irate() — instant rate (gunakan 2 data point terakhir)
irate(http_requests_total[5m])

# Perbedaan rate vs irate:
# rate()  → smooth, good untuk alerting
# irate() → responsive, good untuk dashboards

# sum — total requests across all instances
sum(rate(http_requests_total[5m]))

# sum by label — group by endpoint
sum by (endpoint) (rate(http_requests_total[5m]))

# avg — average CPU usage across nodes
avg(node_cpu_seconds_total{mode="idle"})

# max — highest memory usage
max(node_memory_MemTotal_bytes - node_memory_MemAvailable_bytes)

# min — lowest disk space
min(node_filesystem_avail_bytes{mountpoint="/"})

# topk — top 5 busiest endpoints
topk(5, sum by (endpoint) (rate(http_requests_total[5m])))

# bottomk — bottom 3 slowest instances
bottomk(3, avg by (instance) (rate(http_request_duration_seconds_sum[5m])))

# count — number of instances
count(up == 1)

# stddev — standard deviation of response times
stddev(rate(http_request_duration_seconds_sum[5m]))

# Error rate percentage
sum(rate(http_requests_total{status_code=~"5.."}[5m]))
/
sum(rate(http_requests_total[5m]))
* 100

# Request duration percentiles
histogram_quantile(0.50, rate(http_request_duration_seconds_bucket[5m]))  # p50
histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m]))  # p95
histogram_quantile(0.99, rate(http_request_duration_seconds_bucket[5m]))  # p99

# Saturation: CPU usage percentage per node
100 - (avg by (instance) (irate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

# Memory usage percentage
(1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100

# Disk usage percentage
(1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100

# Network throughput (MB/s)
rate(node_network_receive_bytes_total[5m]) / 1024 / 1024
rate(node_network_transmit_bytes_total[5m]) / 1024 / 1024

# Apdex Score (Application Performance Index)
(
  sum(rate(http_request_duration_seconds_bucket{le="0.1"}[5m]))
  +
  sum(rate(http_request_duration_seconds_bucket{le="0.5"}[5m]))
) / 2
/
sum(rate(http_request_duration_seconds_count[5m]))

# Predict disk full in 4 hours
predict_linear(node_filesystem_avail_bytes{mountpoint="/"}[1h], 4*3600) < 0

# prometheus/rules/alerts.yml
groups:
  - name: application_alerts
    rules:
      # High Error Rate
      - alert: HighErrorRate
        expr: |
          sum(rate(http_requests_total{status_code=~"5.."}[5m]))
          /
          sum(rate(http_requests_total[5m]))
          > 0.05
        for: 5m
        labels:
          severity: critical
          team: backend
        annotations:
          summary: "High 5xx error rate on {{ $labels.instance }}"
          description: "Error rate is {{ $value | humanizePercentage }} (threshold: 5%)"
          runbook_url: "https://wiki.example.com/runbooks/high-error-rate"

      # High Latency
      - alert: HighLatency
        expr: |
          histogram_quantile(0.95, rate(http_request_duration_seconds_bucket[5m])) > 2
        for: 10m
        labels:
          severity: warning
        annotations:
          summary: "High p95 latency on {{ $labels.instance }}"
          description: "p95 latency is {{ $value }}s (threshold: 2s)"

      # Service Down
      - alert: ServiceDown
        expr: up == 0
        for: 1m
        labels:
          severity: critical
        annotations:
          summary: "Service {{ $labels.instance }} is DOWN"
          description: "{{ $labels.job }} on {{ $labels.instance }} has been down for more than 1 minute"

  - name: infrastructure_alerts
    rules:
      # High CPU Usage
      - alert: HighCPUUsage
        expr: |
          100 - (avg by (instance) (irate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 85
        for: 10m
        labels:
          severity: warning
        annotations:
          summary: "High CPU usage on {{ $labels.instance }}"
          description: "CPU usage is {{ $value | printf \"%.1f\" }}%"

      # Low Memory
      - alert: LowMemory
        expr: |
          (1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100 > 90
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "Low memory on {{ $labels.instance }}"
          description: "Memory usage is {{ $value | printf \"%.1f\" }}%"

      # Disk Almost Full
      - alert: DiskAlmostFull
        expr: |
          (1 - node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}) * 100 > 85
        for: 10m
        labels:
          severity: warning
        annotations:
          summary: "Disk almost full on {{ $labels.instance }}"
          description: "Disk usage is {{ $value | printf \"%.1f\" }}%"

      # Disk will be full in 4 hours
      - alert: DiskWillFillSoon
        expr: predict_linear(node_filesystem_avail_bytes{mountpoint="/"}[6h], 4*3600) < 0
        for: 30m
        labels:
          severity: warning
        annotations:
          summary: "Disk on {{ $labels.instance }} predicted to fill within 4 hours"

      # Container Restart Loop
      - alert: ContainerRestartLoop
        expr: increase(kube_pod_container_status_restarts_total[1h]) > 3
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "Container {{ $labels.container }} restarting frequently"
          description: "Pod {{ $labels.pod }} restarted {{ $value }} times in the last hour"

# alertmanager/alertmanager.yml
global:
  resolve_timeout: 5m
  slack_api_url: 'https://hooks.slack.com/services/XXX/YYY/ZZZ'
  smtp_smarthost: 'smtp.gmail.com:587'
  smtp_from: 'alerts@example.com'
  smtp_auth_username: 'alerts@example.com'
  smtp_auth_password: 'app-password'

# Routing rules
route:
  receiver: 'default-slack'
  group_by: ['alertname', 'instance']
  group_wait: 30s
  group_interval: 5m
  repeat_interval: 4h

  routes:
    # Critical alerts → PagerDuty + Slack
    - match:
        severity: critical
      receiver: 'critical-pagerduty'
      group_wait: 10s
      repeat_interval: 1h

    # Warning alerts → Slack only
    - match:
        severity: warning
      receiver: 'warning-slack'
      repeat_interval: 4h

    # Team-specific routing
    - match:
        team: backend
      receiver: 'backend-slack'

# Receivers
receivers:
  - name: 'default-slack'
    slack_configs:
      - channel: '#alerts'
        title: '{{ .GroupLabels.alertname }}'
        text: '{{ range .Alerts }}{{ .Annotations.description }}{{ end }}'

  - name: 'critical-pagerduty'
    pagerduty_configs:
      - service_key: 'your-pagerduty-key'
        severity: 'critical'
    slack_configs:
      - channel: '#alerts-critical'
        color: 'danger'

  - name: 'warning-slack'
    slack_configs:
      - channel: '#alerts-warning'
        color: 'warning'

  - name: 'backend-slack'
    slack_configs:
      - channel: '#backend-alerts'

# Inhibition rules
inhibit_rules:
  - source_match:
      severity: 'critical'
    target_match:
      severity: 'warning'
    equal: ['alertname', 'instance']

# grafana/provisioning/datasources/prometheus.yaml
apiVersion: 1

datasources:
  - name: Prometheus
    type: prometheus
    access: proxy
    url: http://prometheus:9090
    isDefault: true
    editable: true

  - name: Alertmanager
    type: alertmanager
    access: proxy
    url: http://alertmanager:9093
    jsonData:
      implementation: prometheus

{
  "dashboard": {
    "title": "Node Overview",
    "tags": ["infrastructure", "node"],
    "timezone": "browser",
    "panels": [
      {
        "title": "CPU Usage",
        "type": "timeseries",
        "gridPos": {"h": 8, "w": 12, "x": 0, "y": 0},
        "targets": [
          {
            "expr": "100 - (avg by(instance) (irate(node_cpu_seconds_total{mode=\"idle\"}[5m])) * 100)",
            "legendFormat": "{{instance}}"
          }
        ],
        "fieldConfig": {
          "defaults": {
            "unit": "percent",
            "max": 100,
            "thresholds": {
              "steps": [
                {"value": null, "color": "green"},
                {"value": 70, "color": "yellow"},
                {"value": 85, "color": "red"}
              ]
            }
          }
        }
      },
      {
        "title": "Memory Usage",
        "type": "gauge",
        "gridPos": {"h": 8, "w": 12, "x": 12, "y": 0},
        "targets": [
          {
            "expr": "(1 - node_memory_MemAvailable_bytes / node_memory_MemTotal_bytes) * 100",
            "legendFormat": "{{instance}}"
          }
        ],
        "fieldConfig": {
          "defaults": {
            "unit": "percent",
            "min": 0,
            "max": 100,
            "thresholds": {
              "steps": [
                {"value": null, "color": "green"},
                {"value": 80, "color": "yellow"},
                {"value": 90, "color": "red"}
              ]
            }
          }
        }
      },
      {
        "title": "Disk Usage",
        "type": "bargauge",
        "gridPos": {"h": 8, "w": 12, "x": 0, "y": 8},
        "targets": [
          {
            "expr": "(1 - node_filesystem_avail_bytes{mountpoint=\"/\"} / node_filesystem_size_bytes{mountpoint=\"/\"}) * 100",
            "legendFormat": "{{instance}}"
          }
        ]
      },
      {
        "title": "Network I/O",
        "type": "timeseries",
        "gridPos": {"h": 8, "w": 12, "x": 12, "y": 8},
        "targets": [
          {
            "expr": "rate(node_network_receive_bytes_total[5m])",
            "legendFormat": "RX {{instance}}"
          },
          {
            "expr": "rate(node_network_transmit_bytes_total[5m])",
            "legendFormat": "TX {{instance}}"
          }
        ],
        "fieldConfig": {
          "defaults": {"unit": "Bps"}
        }
      }
    ],
    "refresh": "30s",
    "time": {"from": "now-1h", "to": "now"}
  }
}

# Variable: $instance
# Query: label_values(up, instance)
# Result: web1:9100, web2:9100, db1:9100

# Variable: $job
# Query: label_values(up, job)
# Result: node-exporter, prometheus, mysql

# Variable: $interval
# Type: Interval
# Values: 1m, 5m, 15m, 1h, 6h, 1d

# Menggunakan variables di query:
rate(http_requests_total{instance="$instance"}[$interval])
avg by (job) (rate(http_requests_total[$interval]))
node_memory_MemAvailable_bytes{instance=~"$instance"}

# Grafana annotations dari Prometheus alerts
# Otomatis muncul di dashboard ketika alert triggered

# Custom annotations dari data source
# Query: ALERTS{alertstate="firing"}

# Manual annotations dari API
curl -X POST http://admin:admin123@localhost:3000/api/annotations \
  -H "Content-Type: application/json" \
  -d '{
    "dashboardUID": "abc123",
    "time": 1625097600000,
    "text": "Deployed v2.0.0",
    "tags": ["deploy", "v2.0.0"]
  }'

# Grafana provisioning alert rules
# grafana/provisioning/alerting/rules.yaml
apiVersion: 1

groups:
  - orgId: 1
    name: Application Alerts
    folder: Monitoring
    interval: 1m
    rules:
      - uid: high-error-rate
        title: High Error Rate
        condition: C
        data:
          - refId: A
            relativeTimeRange:
              from: 300
              to: 0
            datasourceUid: prometheus
            model:
              expr: 'sum(rate(http_requests_total{status_code=~"5.."}[5m])) / sum(rate(http_requests_total[5m])) * 100'
              instant: true
          - refId: C
            relativeTimeRange:
              from: 300
              to: 0
            datasourceUid: __expr__
            model:
              type: threshold
              expression: A
              conditions:
                - evaluator:
                    type: gt
                    params: [5]
        for: 5m
        labels:
          severity: critical
        annotations:
          summary: "High 5xx error rate detected"
