1. Pengenalan Mobile Security Testing
Mobile Application Security Testing adalah proses evaluasi keamanan aplikasi mobile. Dengan 6.8 miliar pengguna smartphone global, mobile apps menjadi target utama karena menyimpan data sensitif seperti credentials, data finansial, dan informasi pribadi.
- OWASP Mobile Top 10 risks
- Android dan iOS security architecture
- Static dan dynamic analysis
- Reverse engineering mobile apps
- Network traffic interception
- Automated mobile security testing
Mobile Attack Surface
βββββββββββββββββββββββββββββββββββββββββββββββββββββββ β MOBILE APP ATTACK SURFACE β β β β ββββββββββββββββββββββββββββββββββββββββββββββββ β β β MOBILE DEVICE β β β β βββββββββββ βββββββββββ ββββββββββββ β β β β β App β β OS β β Hardware β β β β β ββ’ Storageβ ββ’ Root/ β ββ’ Secure β β β β β ββ’ Code β β Jailbrkβ β Enclave β β β β β ββ’ IPC β ββ’ Sandboxβ ββ’ Biometr β β β β β ββ’ Memory β ββ’ Perms β ββ’ NFC/BLE β β β β β βββββββββββ βββββββββββ ββββββββββββ β β β ββββββββββββββββββββββββββββββββββββββββββββββββ β β β β β βΌ β β ββββββββββββββββββββββββββββββββββββββββββββββββ β β β NETWORK β β β β β’ MITM/TLS interception β β β β β’ Certificate pinning bypass β β β β β’ API tampering β β β ββββββββββββββββββββββββββββββββββββββββββββββββ β βββββββββββββββββββββββββββββββββββββββββββββββββββββββ
2. OWASP Mobile Top 10 (2024)
| # | Risiko | Deskripsi |
|---|---|---|
| M1 | Improper Credential Usage | Hardcoded credentials, insecure storage |
| M2 | Inadequate Supply Chain Security | Compromised SDK, malicious libraries |
| M3 | Insecure Authentication | Weak auth, missing checks |
| M4 | Insufficient Input Validation | Injection, XSS, buffer overflow |
| M5 | Insecure Communication | No TLS, weak cipher |
| M6 | Inadequate Privacy Controls | Data leakage, PII exposure |
| M7 | Insufficient Binary Protections | No obfuscation, debug enabled |
| M8 | Security Misconfiguration | Debug mode, backup enabled |
| M9 | Insecure Data Storage | Plaintext, world-readable |
| M10 | Insufficient Cryptography | Weak algorithm, hardcoded keys |
3. Android Testing Environment
# =============================================
+# Android Security Testing Environment
+# =============================================
+# 1. Install tools
+pip install frida-tools objection drozer
+# 2. Setup Burp Suite proxy
+# Burp > Proxy > Options > Add: all interfaces:8080
+# Mobile: WiFi proxy ke laptop IP:8080
+# Install Burp CA certificate
+# 3. Bypass SSL Pinning dengan Frida
+frida -U -f com.target.app -l ssl-bypass.js --no-pause
+# ssl-bypass.js:
+# Java.perform(function() {
+# var TrustManager = Java.registerClass({
+# name: 'com.custom.TrustManager',
+# implements: [Java.use('javax.net.ssl.X509TrustManager')],
+# methods: {
+# checkClientTrusted: function(chain, authType) {},
+# checkServerTrusted: function(chain, authType) {},
+# getAcceptedIssuers: function() { return []; }
+# }
+# });
+# var SSLContext = Java.use('javax.net.ssl.SSLContext');
+# var ctx = SSLContext.getInstance('TLS');
+# ctx.init(null, [TrustManager.$new()], null);
+# });
+# 4. Decompile APK
+apktool d target.apk -o decompiled
+jadx --show-bad-code target.apk -d jadx_out
+# 5. Enumerate components
+drozer console connect
+dz> run app.package.attacksurface com.target.app
+dz> run app.activity.info -a com.target.app
+dz> run app.provider.info -a com.target.app
+dz> run app.broadcast.info -a com.target.app
4. Static Analysis (SAST)
Static analysis menganalisis source code atau binary tanpa menjalankan aplikasi. Menemukan hardcoded secrets, insecure API usage, dan vulnerability pattern.
# ============================================= +# Static Analysis Tools & Techniques +# ============================================= +# 1. MobSF (Mobile Security Framework) +docker run -p 8000:8000 opensecurity/mobsf:latest +# 2. Hardcoded secrets +grep -rn "api_key\|password\|secret\|token" \ + decompiled/smali/ +# 3. Exported components +grep -A5 'exported="true"' decompiled/AndroidManifest.xml +# 4. Insecure cryptography +grep -rn "DES\|RC4\|ECB\|MD5" decompiled/smali/ +# 5. Network security config +cat decompiled/res/xml/network_security_config.xml +# 6. Insecure WebView +grep -rn "setJavaScriptEnabled\|setAllowFileAccess" \ + decompiled/smali/ +# 7. Semgrep +semgrep --config=p/android decompiled/ +semgrep --config=p/owasp-mobile decompiled/
5. Dynamic Analysis (DAST)
Dynamic analysis menguji aplikasi saat berjalan. Menemukan insecure storage, IPC, dan runtime manipulation.
# ============================================= +# Dynamic Analysis Techniques +# ============================================= +# 1. Trace API calls +frida-trace -U -i "open*" com.target.app +# 2. Hook crypto functions +frida -U com.target.app -l crypto-hook.js +# 3. Enumerate stored files +adb shell run-as com.target.app ls -la /data/data/com.target.app/ +adb shell run-as com.target.app cat /data/data/com.target.app/shared_prefs/*.xml +# 4. Content Provider leaks +adb shell content query --uri content://com.target.app.provider/users +# 5. Backup vulnerability +adb backup -f backup.ab com.target.app +java -jar abe.jar unpack backup.ab backup.tar +tar xf backup.tar
6. iOS Security Testing
# ============================================= +# iOS Security Testing Setup +# ============================================= +# Requirements: Jailbroken iPhone (palera1n/Dopamine) +# 1. Explore filesystem +objection -g "com.target.app" explore +[objection] ls /var/mobile/Containers/Data/Application/ +# 2. Bypass jailbreak detection +frida -U -f com.target.app -l ios-jb-bypass.js --no-pause +# 3. Bypass SSL pinning +objection -g com.target.app explore +[objection] ios sslpinning disable +# 4. Dump keychain +[objection] ios keychain dump +# 5. Binary analysis +class-dump -H TargetApp.app/TargetApp +otool -L TargetApp.app/TargetApp
7. Network Traffic Analysis
# ============================================= +# Mobile Network Traffic Analysis +# ============================================= +# 1. mitmproxy +mitmweb --listen-port 8080 +# 2. Install CA certificate +# Download http://mitm.it di mobile browser +# Android: Settings > Security > Install certificate +# iOS: Settings > General > Profile > Install +# 3. Monitor with tcpdump +adb shell tcpdump -i any -s 0 -w /sdcard/capture.pcap +adb pull /sdcard/capture.pcap +# 4. Bypass certificate pinning +objection -g com.target.app explore +[objection] android sslpinning disable +# 5. ReFlutter (Flutter apps) +reflutter target.ipa
8. Automated Testing
# Mobile Security CI/CD Pipeline +name: Mobile Security Scan +on: + push: + branches: [main, develop] +jobs: + security-scan: + runs-on: ubuntu-latest + steps: + - uses: actions/checkout@v4 + - name: MobSF Scan + uses: fundacaociatec/mobsf-action@v1 + with: + file_path: app/build/outputs/apk/debug/app-debug.apk + - name: Semgrep SAST + uses: returntocorp/semgrep-action@v1 + with: + config: p/owasp-mobile
Flutter App Security
Flutter apps memiliki tantangan keamanan khusus karena menggunakan Dart yang dikompilasi ke native code (AOT compilation). Standard Android/iOS reverse engineering tools tidak langsung bekerja pada Flutter.
# ============================================= +# Flutter App Security Testing +# ============================================= +# Flutter apps store Dart code in libapp.so +# Standard decompilers won't work +# 1. ReFlutter β Repackage Flutter app +pip install reflutter +reflutter target.apk +# This patches the app to dump SSL traffic +# 2. Frida for Flutter +# Use rida (Flutter-specific Frida scripts) +git clone https://github.com/aspect-apps/rida +frida -U -f com.target.app -l rida.js --no-pause +# 3. Binary analysis +# Extract libapp.so +unzip target.apk lib/armeabi-v7a/libapp.so +# Use Ghidra or IDA to analyze +# Search for API endpoints in binary +strings libapp.so | grep -i "https://api" +# 4. Dart-specific reverse engineering +# Use blutter for Flutter reverse engineering +git clone https://github.com/aspect-apps/blutter +python3 blutter.py path/to/libapp.so path/to/output +# 5. Intercept Flutter HTTP traffic +# Flutter doesn't use system proxy by default +# Use ProxyDroid (rooted device) to force proxy +# Or patch app with iptables redirect +# 6. Secure Storage analysis +# Flutter flutter_secure_storage uses: +# Android: EncryptedSharedPreferences +# iOS: Keychain +# Check for weak encryption keys
React Native App Security
React Native apps membawa JavaScript bundle yang berisi source code dan business logic. Bundle ini bisa diekstrak dan dibaca langsung.
# ============================================= +# React Native App Analysis +# ============================================= +# 1. Extract JS bundle dari APK +unzip target.apk assets/index.android.bundle +# 2. Beautify dan analisis +js-beautify assets/index.android.bundle > bundle.js + +# 3. Search for sensitive data +grep -i "api_key\|secret\|password\|token" bundle.js +grep -i "https://api" bundle.js + +# 4. Find hardcoded credentials +grep -i "bearer\|authorization" bundle.js + +# 5. Check for debug flags +grep -i "__DEV__\|debug\|DEV_MODE" bundle.js + +# 6. Find environment configs +grep -i "staging\|production\|localhost" bundle.js + +# 7. Hermes bytecode (if Hermes engine enabled) +# Hermes compiles JS to bytecode +# Use hermes-dec to decompile: +git clone https://github.com/P1sec/hermes-dec +python3 hermes-dec/bytecode_dec.py index.android.bundle + +# Defense: +# - Enable ProGuard/R8 obfuscation +# - Use Hermes engine (compiled bytecode) +# - Don't store secrets in JS bundle +# - Use env-specific builds (not JS checks)
Mobile App Hardening Checklist
| Category | Control | Implementation |
|---|---|---|
| Data Storage | Encrypt sensitive data | Keychain (iOS), EncryptedSharedPreferences (Android) |
| Network | Certificate pinning | TrustManager, NSAppTransportSecurity |
| Authentication | Biometric + MFA | BiometricPrompt, LocalAuthentication |
| Code | Obfuscation | ProGuard/R8 (Android), SwiftShield (iOS) |
| Tamper | Tamper detection | Root/jailbreak detection, integrity checks |
| Debug | Disable debugging | android:debuggable=false, strip symbols |
Mobile Malware Analysis
Analisis malware mobile membantu memahami teknik yang digunakan attacker untuk menginfeksi dan mencuri data dari perangkat mobile.
# =============================================
+# Mobile Malware Analysis
+# =============================================
+# 1. Install malware di emulator (isolated)
+adb install suspicious_app.apk
+# 2. Monitor network traffic
+adb shell tcpdump -i any -w /sdcard/capture.pcap &
+# Open suspicious app, use features
+adb pull /sdcard/capture.pcap
+# 3. Analyze network with Wireshark
+wireshark capture.pcap
+# Look for:
+# - C2 server communication
+# - Data exfiltration (POST requests)
+# - DGA (Domain Generation Algorithm) patterns
+# 4. Monitor file system changes
+adb shell inotifywait -m -r /data/data/com.suspicious.app/
+# 5. API monitoring with Frida
+frida -U com.suspicious.app -l api-monitor.js
+# api-monitor.js:
+# Interceptor.attach(Module.findExportByName(null, 'connect'), {
+# onEnter: function(args) {
+# console.log('connect() called');
+# }
+# });
+# 6. Check for overlay attack capability
+# Look for SYSTEM_ALERT_WINDOW permission
+grep "SYSTEM_ALERT_WINDOW" AndroidManifest.xml
+# 7. Check for SMS interception
+# Look for RECEIVE_SMS, READ_SMS permissions
+grep -i "sms" AndroidManifest.xml
+# 8. Check for screen recording
+# Look for MEDIA_PROJECTION permission
+grep "MEDIA_PROJECTION" AndroidManifest.xml
+ Common Mobile Vulnerabilities
+| Vulnerability | Platform | Impact |
|---|---|---|
| Insecure WebView | Android | XSS, file access, JS injection |
| Exported Components | Android | Unauthorized access to activities/services |
| Weak Keychain | iOS | Data accessible without biometric |
| Clipboard Exposure | Both | Sensitive data in clipboard |
| Screenshot Leak | Both | App screens captured in recent apps |
| Debug Build | Both | Debug info exposed, easy reverse engineering |
iOS App Transport Security
App Transport Security (ATS) pada iOS memaksa semua koneksi menggunakan HTTPS. Banyak developer yang men-disable ATS sepenuhnya, yang mengakibatkan data rentan terhadap interception.
<!-- YANG HARUS DIHINDARI di Info.plist --> +<key>NSAppTransportSecurity</key> +<dict> + <key>NSAllowsArbitraryLoads</key> + <true/> <!-- KRITIS: Mengizinkan semua HTTP --> +</dict> + +<!-- YANG BENAR: Hanya exception spesifik --> +<key>NSAppTransportSecurity</key> +<dict> + <key>NSExceptionDomains</key> + <dict> + <key>api.example.com</key> + <dict> + <key>NSExceptionRequiresForwardSecrecy</key> + <true/> + <key>NSIncludesSubdomains</key> + <true/> + </dict> + </dict> +</dict>+
Mobile Security Resources
+-
+
- OWASP MASTG β Mobile Application Security Testing Guide +
- OWASP MASVS β Mobile Application Security Verification Standard +
- HackTheBox β Mobile challenges untuk praktik +
- DIVA Android β Insecure app untuk belajar +
- OWASP iGoat β iOS security learning tool +
9. Quiz Pemahaman
1. Peringkat #1 OWASP Mobile Top 10 2024?
2. Tool hook fungsi Java runtime Android?
3. Fungsi certificate pinning?
4. Command decompile APK dengan APKTool?
5. Mengapa backup-enabled berisiko?
Rangkuman
- OWASP Mobile β 10 risiko kritis mobile app security
- Static Analysis β MobSF, semgrep, manual grep untuk hardcoded secrets
- Dynamic Analysis β Frida untuk runtime hooking dan bypass
- SSL Pinning β Bisa di-bypass dengan Frida atau objection
- Backup β Android backup bisa mengekstrak data sensitif
