MLflow untuk Experiment Tracking — Runs, Metrics, Model Registry & Deployment

# Instalasi MLflow
pip install mlflow

# Verifikasi
mlflow --version

# Jalankan MLflow UI
mlflow ui
# Buka http://localhost:5000

# Atau jalankan dengan backend store
mlflow ui --backend-store-uri sqlite:///mlflow.db --port 5000

# Untuk production, gunakan remote server
# mlflow server --backend-store-uri postgresql://... --default-artifact-root s3://...

# =============================================
# MLflow Experiment & Runs
# =============================================
import mlflow
import mlflow.sklearn

# Set experiment (grouping runs)
mlflow.set_experiment("prediksi-harga-rumah")

# ----- Run 1: Linear Regression -----
with mlflow.start_run(run_name="linear-regression-v1"):
    # Log parameters
    mlflow.log_param("model_type", "LinearRegression")
    mlflow.log_param("fit_intercept", True)
    mlflow.log_param("normalize", False)

    # Training
    from sklearn.linear_model import LinearRegression
    model = LinearRegression(fit_intercept=True)
    model.fit(X_train, y_train)

    # Evaluate
    from sklearn.metrics import mean_squared_error, r2_score
    predictions = model.predict(X_test)
    mse = mean_squared_error(y_test, predictions)
    r2 = r2_score(y_test, predictions)

    # Log metrics
    mlflow.log_metric("mse", mse)
    mlflow.log_metric("rmse", mse ** 0.5)
    mlflow.log_metric("r2", r2)

    # Log tags
    mlflow.set_tag("developer", "budi")
    mlflow.set_tag("dataset", "rumah-jakarta-v2")

    # Log model
    mlflow.sklearn.log_model(model, "model")

    print(f"Run ID: {mlflow.active_run().info.run_id}")
    print(f"MSE: {mse:.4f}, R²: {r2:.4f}")

# ----- Run 2: Random Forest -----
with mlflow.start_run(run_name="random-forest-v1"):
    mlflow.log_param("model_type", "RandomForest")
    mlflow.log_param("n_estimators", 100)
    mlflow.log_param("max_depth", 10)

    from sklearn.ensemble import RandomForestRegressor
    rf = RandomForestRegressor(n_estimators=100, max_depth=10, random_state=42)
    rf.fit(X_train, y_train)

    predictions = rf.predict(X_test)
    mse = mean_squared_error(y_test, predictions)
    r2 = r2_score(y_test, predictions)

    mlflow.log_metric("mse", mse)
    mlflow.log_metric("rmse", mse ** 0.5)
    mlflow.log_metric("r2", r2)

    mlflow.sklearn.log_model(rf, "model")

# =============================================
# Logging Metrics per Step (Epoch)
# =============================================
import mlflow

with mlflow.start_run(run_name="xgboost-detailed"):
    # Log params
    mlflow.log_params({
        "model": "XGBoost",
        "n_estimators": 200,
        "max_depth": 6,
        "learning_rate": 0.1,
        "subsample": 0.8,
        "colsample_bytree": 0.8
    })

    # Training dengan logging per epoch
    for epoch in range(num_epochs):
        model.fit(X_train, y_train, xgb_model=prev_model)

        train_loss = evaluate(model, X_train, y_train)
        val_loss = evaluate(model, X_val, y_val)
        val_r2 = r2_score(y_val, model.predict(X_val))

        # Log metric dengan step (epoch)
        mlflow.log_metric("train_loss", train_loss, step=epoch)
        mlflow.log_metric("val_loss", val_loss, step=epoch)
        mlflow.log_metric("val_r2", val_r2, step=epoch)

    # Log metrics dengan step (epoch)
    mlflow.log_metric("train_loss", train_loss, step=epoch)
    mlflow.log_metric("val_loss", val_loss, step=epoch)
    mlflow.log_metric("val_r2", val_r2, step=epoch)

# =============================================
# Logging Artifacts
# =============================================
import mlflow
import matplotlib.pyplot as plt
import joblib

with mlflow.start_run(run_name="with-artifacts"):
    # ... training code ...

    # 1. Save & log plot
    fig, ax = plt.subplots()
    ax.plot(history["loss"], label="Train Loss")
    ax.plot(history["val_loss"], label="Val Loss")
    ax.legend()
    plt.savefig("loss_curve.png")
    mlflow.log_artifact("loss_curve.png", artifact_path="plots")

    # 2. Log confusion matrix
    from sklearn.metrics import confusion_matrix, ConfusionMatrixDisplay
    cm = confusion_matrix(y_test, predictions)
    disp = ConfusionMatrixDisplay(cm)
    disp.plot()
    plt.savefig("confusion_matrix.png")
    mlflow.log_artifact("confusion_matrix.png", artifact_path="plots")

    # 3. Log model file
    joblib.dump(model, "model.pkl")
    mlflow.log_artifact("model.pkl", artifact_path="models")

    # 4. Log sklearn model (recommended)
    mlflow.sklearn.log_model(
        model,
        artifact_path="model",
        registered_model_name="harga-rumah-model",
        input_example=X_train[:3],
        signature=mlflow.models.infer_signature(X_train, predictions)
    )

    # 5. Log dataset artifact
    mlflow.log_artifact("data/train.csv", artifact_path="datasets")

# =============================================
# Compare Runs
# =============================================
import mlflow
from mlflow.tracking import MlflowClient

client = MlflowClient()
experiment = client.get_experiment_by_name("prediksi-harga-rumah")

# Search runs
runs = mlflow.search_runs(
    experiment_ids=[experiment.experiment_id],
    filter_string="metrics.r2 > 0.7",
    order_by=["metrics.r2 DESC"],
    max_results=10
)

# Print results
print("Top runs by R²:")
for _, run in runs.iterrows():
    print(f"  {run['run_name']}: R²={run['metrics.r2']:.4f}, "
          f"MSE={run['metrics.mse']:.4f}")

# Get best run
best_run = runs.iloc[0]
best_model_uri = f"runs:/{best_run['run_id']}/model"
print(f"\nBest model: {best_model_uri}")

# Compare parameters
cols_to_compare = [
    "params.model_type", "params.n_estimators", "params.max_depth",
    "metrics.r2", "metrics.mse", "metrics.rmse"
]
print(runs[cols_to_compare].to_string())

# MLflow UI: buka http://localhost:5000
# → Select experiment → Compare runs → Pilih 2+ runs
# → Lihat scatter plot, parallel coordinates, box plot

# =============================================
# Model Registry
# =============================================
import mlflow
from mlflow.tracking import MlflowClient

client = MlflowClient()

# 1. Register model (saat log_model)
with mlflow.start_run():
    mlflow.sklearn.log_model(
        model, "model",
        registered_model_name="harga-rumah-predictor"
    )

# 2. Transition model stages
model_name = "harga-rumah-predictor"
latest_version = client.get_latest_versions(model_name, stages=["None"])[0]

# Staging
client.transition_model_version_stage(
    name=model_name,
    version=latest_version.version,
    stage="Staging"
)

# Setelah testing → Production
client.transition_model_version_stage(
    name=model_name,
    version=latest_version.version,
    stage="Production"
)

# 3. Load model berdasarkan stage
staging_model = mlflow.pyfunc.load_model(f"models:/{model_name}/Staging")
production_model = mlflow.pyfunc.load_model(f"models:/{model_name}/Production")

# 4. Add description
client.update_model_version(
    name=model_name,
    version=latest_version.version,
    description="Model Random Forest dengan R²=0.89, di-train pada data Juni 2026"
)

# 5. Archive model lama
for mv in client.search_model_versions(f"name='{model_name}'"):
    if mv.current_stage == "Production" and mv.version != latest_version.version:
        client.transition_model_version_stage(
            name=model_name, version=mv.version, stage="Archived"
        )

# =============================================
# Deployment Options
# =============================================

# 1. Serve model sebagai REST API
mlflow models serve -m "models:/harga-rumah-predictor/Production" -p 5001

# Test endpoint
curl -X POST http://localhost:5001/invocations \
  -H "Content-Type: application/json" \
  -d '{"dataframe_split": {"columns": ["luas", "kamar", "lokasi"],
       "data": [[120, 3, "jakarta-selatan"]]}}'

# 2. Docker deployment
mlflow models build-docker -m "models:/harga-rumah-predictor/Production" -n "harga-rumah-api"
docker run -p 5001:8080 harga-rumah-api

# 3. Deploy ke cloud (Azure ML, AWS SageMaker, Databricks)
# mlflow deployments create -t sagemaker -m model_name ...

# =============================================
# Autologging (otomatis!)
# =============================================
import mlflow

# Enable autolog untuk sklearn
mlflow.sklearn.autolog()

# Sekarang SEMUA sklearn training otomatis ter-log!
from sklearn.ensemble import RandomForestRegressor
mlflow.set_experiment("autolog-demo")

with mlflow.start_run():
    model = RandomForestRegressor(n_estimators=100, max_depth=10)
    model.fit(X_train, y_train)
    # → Parameters, metrics, model otomatis ter-log!

# Autolog untuk framework lain:
mlflow.pytorch.autolog()     # PyTorch
mlflow.tensorflow.autolog()  # TensorFlow
mlflow.keras.autolog()       # Keras
mlflow.xgboost.autolog()     # XGBoost
mlflow.lightgbm.autolog()    # LightGBM

# =============================================
# Hyperparameter Search + MLflow
# =============================================
from sklearn.model_selection import GridSearchCV

param_grid = {
    "n_estimators": [50, 100, 200],
    "max_depth": [5, 10, 15],
    "min_samples_split": [2, 5, 10]
}

mlflow.set_experiment("grid-search-rf")

with mlflow.start_run(run_name="grid-search"):
    grid = GridSearchCV(
        RandomForestRegressor(random_state=42),
        param_grid, cv=5, scoring="r2", n_jobs=-1
    )
    grid.fit(X_train, y_train)

    # Log best results
    mlflow.log_params(grid.best_params_)
    mlflow.log_metric("best_cv_r2", grid.best_score_)
    mlflow.sklearn.log_model(grid.best_estimator_, "best_model")

    # Log all results
    for i, params in enumerate(grid.cv_results_["params"]):
        with mlflow.start_run(run_name=f"config-{i}", nested=True):
            mlflow.log_params(params)
            mlflow.log_metric("mean_cv_r2", grid.cv_results_["mean_test_score"][i])
