Kubernetes Helm: Package Manager

📋 Daftar Isi

Pengenalan Helm
Instalasi Helm
Helm Charts
Helm Values & Customization
Helm Releases
Helm Repositories
Membuat Chart Sendiri
Helm Template Functions
Helm Plugins & Ecosystem
Best Practices
Quiz Pemahaman

1. Pengenalan Helm

Helm adalah package manager resmi untuk Kubernetes. Sama seperti apt atau npm mengelola paket di sistem operasi atau Node.js, Helm mengelola paket aplikasi di Kubernetes. Paket-paket ini disebut chart — sekumpulan file YAML yang didefinisikan untuk menginstal, memperbarui, atau menghapus aplikasi di cluster Kubernetes.

Dengan hanya satu perintah helm install, Anda bisa mendeployseluruh stack aplikasi — termasuk Deployment, Service, ConfigMap, Secret, Ingress, dan resource Kubernetes lainnya — tanpa perlu menulis puluhan bahkan ratusan file YAML secara manual.

Mengapa Helm Penting?

Manfaat	Penjelasan
Packaging	Mengemas semua Kubernetes manifests menjadi satu unit yang bisa di-share dan di-install ulang
Templating	Variable dan conditionals memungkinkan satu chart dikonfigurasi untuk banyak environment
Release Management	Setiap instalasi Helm disebut release, memungkinkan rollback dan history
Repositori	Berbagi chart melalui repository seperti ArtifactHub atau ChartMuseum
Dependency Management	Chart bisa memiliki sub-chart sebagai dependency, mirip npm package.json
Rollback	Sangat mudah melakukan rollback ke versi sebelumnya jika ada masalah

Diagram: # Buat chart baru dengan nama "web-app"

/"No. Buat chart baru dengan nama 'web-app'"/
/"Chart.yaml"/
/".helmignore"/
charts/
/"templates/"/
/"deployment.yaml"/
/"service.yaml"/
/"serviceaccount.yaml"/
/"hpa.yaml"/
/"ingress.yaml"/
/"_helpers.tpl"/
/"NOTES.txt"/
tests/
/"test-connection.yaml"/
/"values.yaml"/

Langkah 2: Edit Chart.yaml

YAML

apiVersion: v2
name: web-app
description: Chart Helm untuk aplikasi web BeebaneLabs
type: application
version: 0.1.0
appVersion: "1.0.0"
maintainers:
  - name: BeebaneLabs
    email: dev@beebanelabs.com

Langkah 3: Konfigurasi Values

YAML

# values.yaml untuk aplikasi web
replicaCount: 2

image:
  repository: beebanelabs/web-app
  pullPolicy: IfNotPresent
  tag: "1.0.0"

serviceAccount:
  create: true
  name: ""
  annotations: {}

podAnnotations:
  prometheus.io/scrape: "true"
  prometheus.io/port: "9090"

service:
  type: ClusterIP
  port: 80

ingress:
  enabled: false
  className: nginx
  annotations: {}
  hosts:
    - host: web-app.local
      paths:
        - path: /
          pathType: ImplementationSpecific
  tls: []

resources:
  limits:
    cpu: 500m
    memory: 256Mi
  requests:
    cpu: 100m
    memory: 128Mi

autoscaling:
  enabled: false
  minReplicas: 1
  maxReplicas: 10
  targetCPUUtilizationPercentage: 80

nodeSelector: {}
tolerations: []
affinity: {}

Langkah 4: Buat Deployment Template

YAML (Template)

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ include "web-app.fullname" . }}
  labels:
    {{- include "web-app.labels" . | nindent 4 }}
spec:
  {{- if not .Values.autoscaling.enabled }}
  replicas: {{ .Values.replicaCount }}
  {{- end }}
  selector:
    matchLabels:
      {{- include "web-app.selectorLabels" . | nindent 6 }}
  template:
    metadata:
      {{- with .Values.podAnnotations }}
      annotations:
        {{- toYaml . | nindent 8 }}
      {{- end }}
      labels:
        {{- include "web-app.selectorLabels" . | nindent 8 }}
    spec:
      serviceAccountName: {{ include "web-app.serviceAccountName" . }}
      containers:
        - name: {{ .Chart.Name }}
          image: "{{ .Values.image.repository }}:{{ .Values.image.tag }}"
          imagePullPolicy: {{ .Values.image.pullPolicy }}
          ports:
            - name: http
              containerPort: 80
              protocol: TCP
          livenessProbe:
            httpGet:
              path: /healthz
              port: http
            initialDelaySeconds: 15
            periodSeconds: 10
          readinessProbe:
            httpGet:
              path: /ready
              port: http
            initialDelaySeconds: 5
            periodSeconds: 5
          {{- with .Values.resources }}
          resources:
            {{- toYaml . | nindent 12 }}
          {{- end }}
      {{- with .Values.nodeSelector }}
      nodeSelector:
        {{- toYaml . | nindent 8 }}
      {{- end }}
      {{- with .Values.affinity }}
      affinity:
        {{- toYaml . | nindent 8 }}
      {{- end }}
      {{- with .Values.tolerations }}
      tolerations:
        {{- toYaml . | nindent 8 }}
      {{- end }}

Langkah 5: Build, Test, dan Install

Bash

# Lint chart (validasi syntax)
helm lint web-app/

# Render template (preview output YAML)
helm template my-release web-app/

# Dry-run install
helm install my-release web-app/ --dry-run --debug

# Install chart
helm install my-release web-app/ \
  --set image.tag=1.0.0 \
  --set replicaCount=3

# Package chart untuk distribusi
helm package web-app/

# Install test
helm test my-release

_helpers.tpl: Template Helpers

Go Template

{{/*
Expand the name of the chart.
*/}}
{{- define "web-app.name" -}}
{{- default .Chart.Name .Values.nameOverride | trunc 63 | trimSuffix "-" }}
{{- end }}

{{/*
Create a default fully qualified app name.
*/}}
{{- define "web-app.fullname" -}}
{{- if .Values.fullnameOverride }}
{{- .Values.fullnameOverride | trunc 63 | trimSuffix "-" }}
{{- else }}
{{- $name := default .Chart.Name .Values.nameOverride }}
{{- if contains $name .Release.Name }}
{{- .Release.Name | trunc 63 | trimSuffix "-" }}
{{- else }}
{{- printf "%s-%s" .Release.Name $name | trunc 63 | trimSuffix "-" }}
{{- end }}
{{- end }}
{{- end }}

{{/*
Common labels
*/}}
{{- define "web-app.labels" -}}
helm.sh/chart: {{ .Chart.Name }}-{{ .Chart.Version }}
{{ include "web-app.selectorLabels" . }}
app.kubernetes.io/managed-by: {{ .Release.Service }}
{{- end }}

{{/*
Selector labels
*/}}
{{- define "web-app.selectorLabels" -}}
app.kubernetes.io/name: {{ include "web-app.name" . }}
app.kubernetes.io/instance: {{ .Release.Name }}
{{- end }}

8. Helm Template Functions

Helm menggunakan engine templating Go yang sangat powerful. Memahami fungsi-fungsi template memungkinkan Anda membuat chart yang lebih dinamis dan fleksibel.

Fungsi Dasar

Go Template

# Akses values
{{ .Values.image.repository }}
{{ .Values.replicaCount }}

# Akses chart metadata
{{ .Chart.Name }}
{{ .Chart.Version }}

# Akses release info
{{ .Release.Name }}
{{ .Release.Namespace }}

# Default value (jika kosong, pakai default)
{{ .Values.image.tag | default "latest" }}

# Conditional (if/else)
{{- if .Values.ingress.enabled }}
# Ingress configuration
{{- end }}

# Range (loop)
{{- range .Values.ingress.hosts }}
  - host: {{ .host }}
{{- end }}

# With (scope change)
{{- with .Values.resources }}
resources:
  limits:
    cpu: {{ .limits.cpu }}
{{- end }}

# toYaml (convert ke yaml)
{{ toYaml .Values.resources | nindent 10 }}

# quote & squote
{{ .Values.image.repository | quote }}

# printf (format string)
{{ printf "%s-%s" .Release.Name .Chart.Name }}

# required (wajib diisi)
{{ required "Image repository wajib diisi!" .Values.image.repository }}

# fail (hentikan rendering dengan error)
{{ fail "Error: ingress host harus diisi" }}

Fungsi Sprig (Tambahan Helm)

Helm mendukung library Sprig yang menyediakan ratusan fungsi tambahan:

Go Template

# String manipulation
{{ .Values.name | upper }}           # "HELLO"
{{ .Values.name | lower }}           # "hello"
{{ .Values.name | title }}           # "Hello"
{{ .Values.name | trunc 5 }}         # "Hello" (truncate)
{{ .Values.name | replace "o" "0" }} # "Hell0"

# Lists & Dicts
{{ list "a" "b" "c" }}             # [a b c]
{{ dict "key1" "val1" "key2" "val2" }}
{{ keys .Values.config }}           # list semua keys
{{ hasKey .Values.config "debug" }} # true/false

# Math
{{ add 1 2 }}                       # 3
{{ mul 2 3 }}                       # 6
{{ div 10 3 }}                      # 3
{{ mod 10 3 }}                      # 1
{{ add 1 2 3 }}                     # 6

# Encoding
{{ "hello" | b64enc }}              # base64 encode
{{ "aGVsbG8=" | b64dec }}          # base64 decode

# Crypto
{{ sha256sum "hello" }}             # SHA256 hash

# Type conversion
{{ int64 .Values.replicas }}
{{ toString .Values.port }}

# Semua fungsi Sprig
# https://masterminds.github.io/sprig/

Kondisional Lanjutan

Go Template

# if/else if/else
{{- if eq .Values.env "production" }}
replicas: 5
{{- else if eq .Values.env "staging" }}
replicas: 2
{{- else }}
replicas: 1
{{- end }}

# not, and, or
{{- if and .Values.ingress.enabled .Values.tls.enabled }}
# TLS ingress
{{- end }}

{{- if or .Values.debug .Values.verbose }}
logLevel: debug
{{- end }}

{{- if not .Values.serviceAccount.create }}
# Use existing service account
{{- end }}

# ne (not equal), contains, has
{{- if ne .Values.image.tag "latest" }}
imagePullPolicy: IfNotPresent
{{- end }}

{{- if contains "prod" .Release.Name }}
resources:
  limits:
    cpu: 1000m
{{- end }}

# Regex
{{- if regexMatch "^v[0-9]+" .Values.image.tag }}
# Semver tag detected
{{- end }}

9. Helm Plugins & Ecosystem

Helm memiliki ekosistem plugin yang memperluas fungsinya. Plugin bisa ditambahkan untuk keamanan, manajemen secrets, dan integrasi dengan tools lain.

Plugin Populer

Plugin	Fungsi	Instalasi
helm-secrets	Enkripsi/decryption values menggunakan SOPS	`helm plugin install https://github.com/jkroepke/helm-secrets`
helm-diff	Preview perubahan sebelum upgrade	`helm plugin install https://github.com/databus23/helm-diff`
helmfile	Declarative spec untuk multiple releases	`brew install helmfile`
helm-git	Install chart dari Git repository	`helm plugin install https://github.com/aslafy-z/helm-git`
helm unittest	Unit testing untuk chart	`helm plugin install https://github.com/helm-unittest/helm-unittest`
helm-cm-push	Push chart ke OCI registry	`helm plugin install https://github.com/chartmuseum/helm-push`

Contoh: helm-secrets

Bash

# Instalasi helm-secrets
helm plugin install https://github.com/jkroepke/helm-secrets

# Enkripsi values file
sops --encrypt --in-place secrets.yaml
# Hasil: secrets.yaml (encrypted)

# Install dengan secrets
helm secrets upgrade my-release bitnami/nginx \
  -f values.yaml \
  -f secrets://secrets.yaml

# Lihat decrypted values
helm secrets view secrets.yaml

Contoh: helmfile

YAML

# helmfile.yaml - Declarative Helm releases
repositories:
  - name: bitnami
    url: https://charts.bitnami.com/bitnami
  - name: grafana
    url: https://grafana.github.io/helm-charts

releases:
  - name: nginx-ingress
    namespace: ingress-system
    chart: ingress-nginx/ingress-nginx
    version: 4.10.0
    values:
      - controller:
          replicaCount: 2
          resources:
            limits:
              cpu: 500m
              memory: 256Mi

  - name: monitoring
    namespace: monitoring
    chart: grafana/kube-prometheus-stack
    version: 61.0.0
    values:
      - grafana:
          adminPassword: admin123
      - prometheus:
          retention: 30d

  - name: my-app
    namespace: production
    chart: ./charts/my-app
    values:
      - values-production.yaml

Unit Testing Chart

YAML

# tests/deployment_test.yaml
suite: deployment tests
templates:
  - deployment.yaml
tests:
  - it: should create deployment with correct name
    set:
      nameOverride: my-app
    asserts:
      - isKind:
          of: Deployment
      - matchRegex:
          path: metadata.name
          pattern: my-app

  - it: should set correct replica count
    set:
      replicaCount: 3
    asserts:
      - equal:
          path: spec.replicas
          value: 3

  - it: should use correct image
    set:
      image:
        repository: my-app
        tag: "2.0"
    asserts:
      - equal:
          path: spec.template.spec.containers[0].image
          value: "my-app:2.0"

  - it: should not create HPA when autoscaling disabled
    set:
      autoscaling:
        enabled: false
    asserts:
      - hasDocuments:
          count: 1

10. Best Practices

Mengikuti best practices Helm akan membantu Anda mengelola aplikasi di Kubernetes dengan lebih efektif dan aman. Berikut panduan komprehensif dari BeebaneLabs.

Struktur Chart

Praktik	Rekomendasi
Versi Semver	Gunakan versi semver untuk chart: major.minor.patch (1.0.0)
appVersion	Selalu update appVersion sesuai versi aplikasi yang di-deploy
Minimal Permissions	Jangan berikan RBAC yang terlalu luas di chart
Non-root Container	Selalu jalankan container sebagai user non-root
Health Probes	Sertakan liveness dan readiness probe
Resource Limits	Selalu set resource requests dan limits

Keamanan Chart

Gunakan helm-secrets untuk values yang berisi sensitive data
Jangan pernah hardcode credentials di values.yaml
Gunakan Kubernetes Secret untuk password, API keys, dan certificates
Scan chart dengan trivy atau checkov sebelum deploy
Pin versi image tags, hindari menggunakan latest
Gunakan .helmignore untuk mengecualikan file sensitif

Manajemen Release

Gunakan --atomic untuk auto-rollback jika install gagal
Gunakan --wait untuk memastikan semua resource ready sebelum selesai
Gunakan --timeout untuk mencegah proses hanging
Gunakan namespace terpisah untuk setiap environment (dev, staging, prod)
Simpan values di version control (Git) untuk audit trail

Diagram

Contoh Perintah Production-Ready

Bash

# Install production dengan semua safety net
helm install my-app bitnami/nginx \
  --namespace production \
  --create-namespace \
  -f values-production.yaml \
  --set image.tag=1.27.0 \
  --atomic \
  --wait \
  --timeout 10m \
  --history-max 10

# Upgrade dengan diff preview
helm diff upgrade my-app bitnami/nginx \
  -f values-production.yaml

# Upgrade dengan atomic (auto-rollback on failure)
helm upgrade my-app bitnami/nginx \
  --namespace production \
  -f values-production.yaml \
  --atomic \
  --wait \
  --timeout 10m

# Lihat semua releases di production
helm list -n production -o wide

⚠️ Peringatan

Selalu gunakan --dry-run sebelum melakukan install/upgrade di production. Periksa diff hasil render template sebelum memastikan perubahan aman untuk diterapkan.

Kubernetes Helm: Package Manager

1. Pengenalan Helm

Mengapa Helm Penting?

Langkah 2: Edit Chart.yaml

Langkah 3: Konfigurasi Values

Langkah 4: Buat Deployment Template

Langkah 5: Build, Test, dan Install

_helpers.tpl: Template Helpers

8. Helm Template Functions

Fungsi Dasar

Fungsi Sprig (Tambahan Helm)

Kondisional Lanjutan

9. Helm Plugins & Ecosystem

Plugin Populer

Contoh: helm-secrets

Contoh: helmfile

Unit Testing Chart

10. Best Practices

Struktur Chart

Keamanan Chart

Manajemen Release

Contoh Perintah Production-Ready

11. Quiz Pemahaman

Artikel Terkait

Kubernetes Ingress Controllers

Docker untuk Developer

Ansible: Automation Platform
