Grafana Stack: Mimir + Tempo + Loki

# Tambahkan Grafana Helm repo
helm repo add grafana https://grafana.github.io/helm-charts
helm repo update

# Install Mimir (monolithic mode untuk development)
helm install mimir grafana/mimir-distributed \
  --namespace monitoring --create-namespace \
  --set mimir.structuredConfig.multitenancy_enabled=false \
  --set minio.enabled=true

# Production mode: microservices
# values-mimir-production.yaml
mimir:
  structuredConfig:
    multitenancy_enabled: true
    alertmanager_storage:
      s3:
        bucket_name: mimir-alertmanager
    blocks_storage:
      s3:
        bucket_name: mimir-blocks
    compactor:
      sharding_ring:
        kvstore:
          store: memberlist
    distributor:
      sharding_ring:
        kvstore:
          store: memberlist
    ingester:
      lifecycler:
        ring:
          kvstore:
            store: memberlist
          replication_factor: 3

# Install dengan production values
helm install mimir grafana/mimir-distributed \
  --namespace monitoring \
  --values values-mimir-production.yaml

# Konfigurasi Prometheus untuk remote-write ke Mimir
# prometheus.yml
remote_write:
  - url: http://mimir-nginx.monitoring.svc:80/api/v1/push
    queue_config:
      max_samples_per_send: 5000
      batch_send_deadline: 5s

# Request rate per detik
sum(rate(http_requests_total[5m])) by (service)

# Error rate percentage
sum(rate(http_requests_total{status=~"5.."}[5m])) /
sum(rate(http_requests_total[5m])) * 100

# P99 latency
histogram_quantile(0.99,
  sum(rate(http_request_duration_seconds_bucket[5m])) by (le, service)
)

# Memory usage per pod
container_memory_working_set_bytes{container!=""} /
container_spec_memory_limit_bytes{container!=""} * 100

# CPU usage per node
100 - (avg by(instance) (irate(node_cpu_seconds_total{mode="idle"}[5m])) * 100)

# Disk IOPS
sum(rate(node_disk_reads_completed_total[5m])) by (instance) +
sum(rate(node_disk_writes_completed_total[5m])) by (instance)

# Install Tempo via Helm
helm install tempo grafana/tempo-distributed \
  --namespace monitoring \
  --set storage.trace.backend=s3 \
  --set storage.trace.s3.bucket=tempo-traces \
  --set storage.trace.s3.endpoint=s3.ap-southeast-1.amazonaws.com

# OTel Collector configuration untuk mengirim traces ke Tempo
# otel-collector-config.yaml
receivers:
  otlp:
    protocols:
      grpc:
        endpoint: 0.0.0.0:4317
      http:
        endpoint: 0.0.0.0:4318
  jaeger:
    protocols:
      grpc:
        endpoint: 0.0.0.0:14250
      thrift_http:
        endpoint: 0.0.0.0:14268

processors:
  batch:
    timeout: 5s
    send_batch_size: 1000
  memory_limiter:
    check_interval: 1s
    limit_mib: 512
    spike_limit_mib: 128

exporters:
  otlp/tempo:
    endpoint: tempo-distributor.monitoring:4317
    tls:
      insecure: true
  loki:
    endpoint: http://loki-gateway.monitoring/loki/api/v1/push

service:
  pipelines:
    traces:
      receivers: [otlp, jaeger]
      processors: [memory_limiter, batch]
      exporters: [otlp/tempo]
    logs:
      receivers: [otlp]
      processors: [memory_limiter, batch]
      exporters: [loki]

# TraceQL queries di Grafana Explore
# Cari traces berdasarkan service
{resource.service.name="user-service"}

# Cari traces dengan error
{resource.service.name="user-service" && status=error}

# Cari traces dengan latency tinggi
{duration > 1s}

# Cari span dengan atribut tertentu
{resource.service.name="api-gateway" && span.http.method="POST"}

# Install Loki via Helm
helm install loki grafana/loki-distributed \
  --namespace monitoring \
  --values values-loki.yaml

# values-loki.yaml
loki:
  auth_enabled: false
  commonConfig:
    replication_factor: 1
  storage:
    type: s3
    s3:
      endpoint: s3.ap-southeast-1.amazonaws.com
      region: ap-southeast-1
      bucketnames: loki-logs
  schemaConfig:
    configs:
      - from: "2024-01-01"
        store: tsdb
        object_store: s3
        schema: v13
        index:
          prefix: loki_index_
          period: 24h

# Promtail — agent untuk mengumpulkan logs
# promtail-config.yaml
server:
  http_listen_port: 9080

positions:
  filename: /tmp/positions.yaml

clients:
  - url: http://loki-gateway.monitoring/loki/api/v1/push

scrape_configs:
  # Kubernetes pod logs
  - job_name: kubernetes-pods
    kubernetes_sd_configs:
      - role: pod
    relabel_configs:
      - source_labels: [__meta_kubernetes_pod_label_app]
        target_label: app
      - source_labels: [__meta_kubernetes_namespace]
        target_label: namespace
      - source_labels: [__meta_kubernetes_pod_name]
        target_label: pod
    pipeline_stages:
      - cri: {}
      - json:
          expressions:
            level: level
            msg: message
      - labels:
          level:

# LogQL queries
# Semua logs dari service tertentu
{app="user-service"}

# Logs dengan level error
{app="user-service"} |= "error" | json | level="error"

# Parse JSON logs dan filter
{namespace="production"} | json | status >= 500

# Rate logs error per detik
sum(rate({app="user-service"} |= "error" [5m])) by (pod)

# Extract dan filter field
{app="api-gateway"} | json
  | method = "POST"
  | duration > 1000
  | line_format "{{.method}} {{.path}} {{.duration}}ms"

# Datasource provisioning
# provisioning/datasources/datasources.yaml
apiVersion: 1
datasources:
  # Mimir (Prometheus compatible)
  - name: Mimir
    type: prometheus
    url: http://mimir-nginx.monitoring:80/prometheus
    access: proxy
    isDefault: true
    jsonData:
      httpMethod: POST
      exemplarTraceIdDestinations:
        - name: traceID
          datasourceUid: tempo

  # Tempo
  - name: Tempo
    type: tempo
    url: http://tempo-query-frontend.monitoring:3100
    access: proxy
    uid: tempo
    jsonData:
      tracesToLogsV2:
        datasourceUid: loki
        filterByTraceID: true
        filterBySpanID: true
      tracesToMetrics:
        datasourceUid: mimir
      nodeGraph:
        enabled: true

  # Loki
  - name: Loki
    type: loki
    url: http://loki-gateway.monitoring
    access: proxy
    uid: loki
    jsonData:
      derivedFields:
        - datasourceUid: tempo
          matcherRegex: "traceID=(\\w+)"
          name: TraceID
          url: "$${__value.raw}"

{
  "title": "App Overview - Grafana Stack",
  "panels": [
    {
      "title": "Request Rate",
      "type": "timeseries",
      "targets": [{
        "expr": "sum(rate(http_requests_total[5m])) by (service)",
        "legendFormat": "{{service}}"
      }]
    },
    {
      "title": "Error Rate %",
      "type": "gauge",
      "targets": [{
        "expr": "sum(rate(http_requests_total{status=~'5..'}[5m])) / sum(rate(http_requests_total[5m])) * 100"
      }],
      "fieldConfig": {
        "defaults": {
          "thresholds": {
            "steps": [
              {"value": 0, "color": "green"},
              {"value": 1, "color": "yellow"},
              {"value": 5, "color": "red"}
            ]
          }
        }
      }
    },
    {
      "title": "P99 Latency",
      "type": "timeseries",
      "targets": [{
        "expr": "histogram_quantile(0.99, sum(rate(http_request_duration_seconds_bucket[5m])) by (le, service))"
      }]
    },
    {
      "title": "Recent Errors (Logs)",
      "type": "logs",
      "datasource": "Loki",
      "targets": [{
        "expr": "{namespace='production'} |= 'error' | json | level='error'"
      }]
    }
  ]
}

# Grafana alert rule provisioning
# provisioning/alerting/rules.yaml
apiVersion: 1
groups:
  - orgId: 1
    name: App Health
    folder: Production
    interval: 1m
    rules:
      - uid: high-error-rate
        title: High Error Rate
        condition: C
        data:
          - refId: A
            datasourceUid: mimir
            model:
              expr: |
                sum(rate(http_requests_total{status=~"5.."}[5m])) by (service)
                /
                sum(rate(http_requests_total[5m])) by (service) * 100
          - refId: C
            model:
              type: threshold
              conditions:
                - evaluator:
                    type: gt
                    params: [5]
        for: 5m
        labels:
          severity: critical
          team: platform
        annotations:
          summary: "Error rate above 5% for {{ $labels.service }}"
          description: "Error rate is {{ $value }}%"

      - uid: high-latency
        title: High P99 Latency
        condition: C
        data:
          - refId: A
            model:
              expr: |
                histogram_quantile(0.99,
                  sum(rate(http_request_duration_seconds_bucket[5m])) by (le, service))
        for: 10m
        labels:
          severity: warning
        annotations:
          summary: "P99 latency above 1s for {{ $labels.service }}"

# Contact points — kirim alert ke Slack
# provisioning/alerting/contactpoints.yaml
apiVersion: 1
contactPoints:
  - orgId: 1
    name: slack-alerts
    receivers:
      - uid: slack-prod
        type: slack
        settings:
          url: ${SLACK_WEBHOOK_URL}
          title: "{{ .CommonLabels.alertname }}"
          text: |
            {{ .CommonAnnotations.summary }}
            Severity: {{ .CommonLabels.severity }}
