Docker Compose Advanced: Multi-Service, Networks, Volumes & Profiles

# docker-compose.yml — Full-stack multi-service example
# BeebaneLabs - Docker Compose Advanced Tutorial

services:
  # ===========================
  # REVERSE PROXY (Nginx)
  # ===========================
  nginx:
    image: nginx:1.25-alpine
    container_name: app-proxy
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./nginx/nginx.conf:/etc/nginx/nginx.conf:ro
      - ./nginx/ssl:/etc/nginx/ssl:ro
    depends_on:
      api:
        condition: service_healthy
    networks:
      - frontend
      - backend
    restart: unless-stopped

  # ===========================
  # FRONTEND (React)
  # ===========================
  frontend:
    build:
      context: ./frontend
      dockerfile: Dockerfile
      args:
        - VITE_API_URL=/api
    container_name: app-frontend
    environment:
      - NODE_ENV=production
    volumes:
      - frontend-dist:/app/dist
    networks:
      - frontend
    restart: unless-stopped

  # ===========================
  # BACKEND API (Node.js)
  # ===========================
  api:
    build:
      context: ./backend
      dockerfile: Dockerfile
      target: production
    container_name: app-api
    environment:
      - DATABASE_URL=postgresql://user:${DB_PASSWORD}@postgres:5432/appdb
      - REDIS_URL=redis://redis:6379
      - JWT_SECRET=${JWT_SECRET}
      - NODE_ENV=production
    volumes:
      - ./backend/uploads:/app/uploads
      - api-logs:/app/logs
    depends_on:
      postgres:
        condition: service_healthy
      redis:
        condition: service_healthy
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:4000/health"]
      interval: 15s
      timeout: 5s
      retries: 3
      start_period: 30s
    networks:
      - backend
      - data
    restart: unless-stopped
    deploy:
      resources:
        limits:
          cpus: '1.0'
          memory: 512M
        reservations:
          cpus: '0.25'
          memory: 128M

  # ===========================
  # WORKER (Celery/Python)
  # ===========================
  worker:
    build:
      context: ./worker
      dockerfile: Dockerfile
    container_name: app-worker
    environment:
      - CELERY_BROKER_URL=redis://redis:6379/0
      - DATABASE_URL=postgresql://user:${DB_PASSWORD}@postgres:5432/appdb
    depends_on:
      redis:
        condition: service_healthy
      postgres:
        condition: service_healthy
    networks:
      - backend
      - data
    restart: unless-stopped
    deploy:
      replicas: 2

  # ===========================
  # DATABASE (PostgreSQL)
  # ===========================
  postgres:
    image: postgres:16-alpine
    container_name: app-db
    environment:
      POSTGRES_USER: user
      POSTGRES_PASSWORD: ${DB_PASSWORD}
      POSTGRES_DB: appdb
    volumes:
      - postgres-data:/var/lib/postgresql/data
      - ./database/init.sql:/docker-entrypoint-initdb.d/init.sql:ro
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U user -d appdb"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 30s
    networks:
      - data
    restart: unless-stopped

  # ===========================
  # CACHE (Redis)
  # ===========================
  redis:
    image: redis:7-alpine
    container_name: app-redis
    command: redis-server --appendonly yes --maxmemory 256mb --maxmemory-policy allkeys-lru
    volumes:
      - redis-data:/data
    healthcheck:
      test: ["CMD", "redis-cli", "ping"]
      interval: 10s
      timeout: 3s
      retries: 3
    networks:
      - data
    restart: unless-stopped

# ===========================
# NETWORKS
# ===========================
networks:
  frontend:
    driver: bridge
    ipam:
      config:
        - subnet: 172.20.0.0/16
  backend:
    driver: bridge
    ipam:
      config:
        - subnet: 172.21.0.0/16
  data:
    driver: bridge
    internal: true
    ipam:
      config:
        - subnet: 172.22.0.0/16

# ===========================
# VOLUMES
# ===========================
volumes:
  postgres-data:
    driver: local
  redis-data:
    driver: local
  frontend-dist:
    driver: local
  api-logs:
    driver: local

# Jalankan semua service di background
docker compose up -d

# Jalankan hanya service tertentu
docker compose up -d api postgres redis

# Lihat status semua service
docker compose ps

# Lihat log gabungan semua service
docker compose logs -f

# Lihat log service tertentu
docker compose logs -f api

# Restart satu service
docker compose restart api

# Rebuild dan restart setelah perubahan Dockerfile
docker compose up -d --build api

# Hentikan semua service (pertahankan data)
docker compose down

# Hentikan dan hapus volumes (HATI-HATI: data hilang!)
docker compose down -v

# Scale worker menjadi 3 instance
docker compose up -d --scale worker=3

# Network segmentation strategy
networks:
  # Frontend network — exposed to outside world
  # Hanya Nginx dan frontend app
  frontend:
    driver: bridge
    driver_opts:
      com.docker.network.bridge.name: br-frontend
    ipam:
      driver: default
      config:
        - subnet: 172.20.0.0/16
          gateway: 172.20.0.1
    labels:
      - "app.network=frontend"
      - "app.environment=production"

  # Backend network — internal API communication
  # API, Worker, dan proxy
  backend:
    driver: bridge
    internal: false   # bisa akses internet untuk API calls
    ipam:
      config:
        - subnet: 172.21.0.0/16
    labels:
      - "app.network=backend"

  # Data network — TIDAK bisa akses internet
  # Database, cache, dan storage saja
  data:
    driver: bridge
    internal: true    # TIDAK bisa akses internet!
    ipam:
      config:
        - subnet: 172.22.0.0/16
    labels:
      - "app.network=data"

services:
  postgres-primary:
    image: postgres:16
    networks:
      data:
        aliases:
          - db-primary
          - database
          - postgres

  postgres-replica:
    image: postgres:16
    networks:
      data:
        aliases:
          - db-replica

  api:
    environment:
      # Service lain bisa pakai alias untuk akses
      DATABASE_HOST: db-primary
      REPLICA_HOST: db-replica
    networks:
      - backend
      - data    # API perlu akses ke data network

services:
  nginx:
    networks:
      frontend:
        ipv4_address: 172.20.0.10
      backend:
        ipv4_address: 172.21.0.10

  postgres:
    networks:
      data:
        ipv4_address: 172.22.0.10

services:
  postgres:
    image: postgres:16
    volumes:
      # Named volume dengan mount options
      - type: volume
        source: postgres-data
        target: /var/lib/postgresql/data
        volume:
          nocopy: true

      # Read-only bind mount untuk config
      - type: bind
        source: ./postgres/postgresql.conf
        target: /etc/postgresql/postgresql.conf
        read_only: true

      # Init scripts (read-only)
      - type: bind
        source: ./database/init
        target: /docker-entrypoint-initdb.d
        read_only: true

  api:
    image: node:20-alpine
    volumes:
      # Bind mount untuk development (hot reload)
      - type: bind
        source: ./backend/src
        target: /app/src

      # Named volume untuk uploads
      - type: volume
        source: api-uploads
        target: /app/uploads

      # tmpfs untuk temporary files (RAM-based)
      - type: tmpfs
        target: /app/tmp
        tmpfs:
          size: 100000000    # 100MB limit
          mode: 1777

  redis:
    image: redis:7-alpine
    volumes:
      - type: volume
        source: redis-data
        target: /data
    # Read-only root filesystem
    read_only: true
    tmpfs:
      - /tmp

# Volume definitions dengan driver options
volumes:
  postgres-data:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /data/postgres
    labels:
      com.example.description: "PostgreSQL production data"
      com.example.backup: "daily"

  redis-data:
    driver: local
    labels:
      com.example.description: "Redis AOF persistence"

  api-uploads:
    driver: local

# Backup volume ke file tar
docker run --rm \
  -v myapp_postgres-data:/data:ro \
  -v $(pwd)/backups:/backup \
  alpine tar czf /backup/postgres-data-$(date +%Y%m%d).tar.gz -C /data .

# Restore volume dari file tar
docker run --rm \
  -v myapp_postgres-data:/data \
  -v $(pwd)/backups:/backup \
  alpine tar xzf /backup/postgres-data-20260626.tar.gz -C /data

# List semua volumes
docker volume ls

# Inspect volume
docker volume inspect myapp_postgres-data

# Backup PostgreSQL secara konsisten (lebih aman)
docker compose exec postgres pg_dump -U user appdb > backup.sql

# Restore PostgreSQL
docker compose exec -T postgres psql -U user appdb < backup.sql

services:
  # ===========================
  # SERVICE UTAMA (selalu jalan)
  # ===========================
  api:
    build: ./backend
    profiles: []    # Tidak ada profile = selalu jalan
    depends_on:
      - postgres
      - redis

  postgres:
    image: postgres:16
    volumes:
      - postgres-data:/var/lib/postgresql/data

  redis:
    image: redis:7-alpine

  nginx:
    image: nginx:1.25-alpine
    ports:
      - "80:80"

  # ===========================
  # DEVELOPMENT ONLY
  # ===========================
  frontend-dev:
    build:
      context: ./frontend
      dockerfile: Dockerfile.dev
    profiles:
      - development
    ports:
      - "3000:3000"
    volumes:
      - ./frontend/src:/app/src    # Hot reload
    environment:
      - NODE_ENV=development

  mailhog:
    image: mailhog/mailhog
    profiles:
      - development
    ports:
      - "1025:1025"   # SMTP
      - "8025:8025"   # Web UI

  # ===========================
  # DEBUGGING / ADMIN TOOLS
  # ===========================
  pgadmin:
    image: dpage/pgadmin4
    profiles:
      - debug
      - admin
    environment:
      PGADMIN_DEFAULT_EMAIL: admin@beebanelabs.com
      PGADMIN_DEFAULT_PASSWORD: ${PGADMIN_PASSWORD}
    ports:
      - "5050:80"

  redis-commander:
    image: rediscommander/redis-commander
    profiles:
      - debug
      - admin
    environment:
      REDIS_HOSTS: local:redis:6379
    ports:
      - "8081:8081"

  portainer:
    image: portainer/portainer-ce
    profiles:
      - admin
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - portainer-data:/data
    ports:
      - "9000:9000"

  # ===========================
  # MONITORING
  # ===========================
  prometheus:
    image: prom/prometheus
    profiles:
      - monitoring
    volumes:
      - ./monitoring/prometheus.yml:/etc/prometheus/prometheus.yml:ro
      - prometheus-data:/prometheus
    ports:
      - "9090:9090"

  grafana:
    image: grafana/grafana
    profiles:
      - monitoring
    volumes:
      - grafana-data:/var/lib/grafana
      - ./monitoring/dashboards:/etc/grafana/provisioning/dashboards:ro
    ports:
      - "3000:3000"

  # ===========================
  # TESTING
  # ===========================
  test-runner:
    build:
      context: .
      dockerfile: Dockerfile.test
    profiles:
      - test
    environment:
      - DATABASE_URL=postgresql://test:test@postgres-test:5432/testdb
    depends_on:
      postgres-test:
        condition: service_healthy

  postgres-test:
    image: postgres:16
    profiles:
      - test
    environment:
      POSTGRES_USER: test
      POSTGRES_PASSWORD: test
      POSTGRES_DB: testdb
    tmpfs:
      - /var/lib/postgresql/data   # RAM-based untuk test cepat
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U test"]
      interval: 5s
      timeout: 3s
      retries: 3

volumes:
  postgres-data:
  portainer-data:
  prometheus-data:
  grafana-data:

# Jalankan HANYA service default (tanpa profile)
docker compose up -d

# Aktifkan profile development
docker compose --profile development up -d

# Aktifkan multiple profiles
docker compose --profile debug --profile monitoring up -d

# Aktifkan SEMUA profiles
docker compose --profile development --profile debug --profile admin --profile monitoring --profile test up -d

# Atau gunakan environment variable
COMPOSE_PROFILES=development,debug docker compose up -d

# Jalankan test dengan profile test
docker compose --profile test run --rm test-runner npm test

# Lihat service berdasarkan profile
docker compose --profile admin ps

# .env — untuk Docker Compose variable substitution
# JANGAN commit file ini ke git!

# Database
DB_PASSWORD=super-secret-password-here
DB_NAME=appdb
DB_USER=appuser

# Application
JWT_SECRET=my-jwt-secret-key
API_KEY=sk-1234567890abcdef

# Docker Compose project name
COMPOSE_PROJECT_NAME=myapp

# Image tags (bisa di-override per environment)
API_IMAGE_TAG=latest
FRONTEND_IMAGE_TAG=latest

# .env.example — Template environment variables
# Copy ke .env dan isi dengan nilai yang sesuai

# Database
DB_PASSWORD=CHANGE_ME
DB_NAME=appdb
DB_USER=appuser

# Application
JWT_SECRET=CHANGE_ME
API_KEY=CHANGE_ME

# Docker
COMPOSE_PROJECT_NAME=myapp
API_IMAGE_TAG=latest
FRONTEND_IMAGE_TAG=latest

services:
  api:
    image: myapp/api:${API_IMAGE_TAG:-latest}
    environment:
      # Dari .env file
      - DATABASE_URL=postgresql://${DB_USER}:${DB_PASSWORD}@postgres:5432/${DB_NAME}
      - JWT_SECRET=${JWT_SECRET}

      # Default values (jika tidak ada di .env)
      - NODE_ENV=${NODE_ENV:-production}
      - LOG_LEVEL=${LOG_LEVEL:-info}
      - PORT=${API_PORT:-4000}

      # Literal value (tidak dari .env)
      - SERVICE_NAME=api

    # Atau gunakan env_file untuk bulk import
    env_file:
      - path: ./config/common.env
        required: true
      - path: ./config/secrets.env
        required: false    # Tidak error jika file tidak ada

# Untuk Docker Swarm, gunakan secrets
# Secrets di-mount sebagai file di /run/secrets/

services:
  api:
    image: myapp/api
    secrets:
      - db_password
      - jwt_secret
      - api_key
    environment:
      # Baca secret dari file
      - DB_PASSWORD_FILE=/run/secrets/db_password
      - JWT_SECRET_FILE=/run/secrets/jwt_secret

  postgres:
    image: postgres:16
    secrets:
      - db_password
    environment:
      POSTGRES_PASSWORD_FILE: /run/secrets/db_password

secrets:
  db_password:
    file: ./secrets/db_password.txt
  jwt_secret:
    file: ./secrets/jwt_secret.txt
  api_key:
    external: true    # Sudah ada di Docker Swarm

services:
  # PostgreSQL — gunakan pg_isready
  postgres:
    image: postgres:16
    healthcheck:
      test: ["CMD-SHELL", "pg_isready -U ${DB_USER} -d ${DB_NAME}"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 30s

  # MySQL — gunakan mysqladmin
  mysql:
    image: mysql:8
    healthcheck:
      test: ["CMD", "mysqladmin", "ping", "-h", "localhost", "-u", "root", "-p${DB_PASSWORD}"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 40s

  # Redis — gunakan redis-cli ping
  redis:
    image: redis:7-alpine
    healthcheck:
      test: ["CMD", "redis-cli", "ping"]
      interval: 10s
      timeout: 3s
      retries: 3

  # MongoDB — gunakan mongosh
  mongo:
    image: mongo:7
    healthcheck:
      test: ["CMD", "mongosh", "--eval", "db.adminCommand('ping')"]
      interval: 15s
      timeout: 5s
      retries: 3
      start_period: 30s

  # HTTP API — gunakan curl
  api:
    build: ./backend
    healthcheck:
      test: ["CMD", "curl", "-f", "http://localhost:4000/health"]
      interval: 15s
      timeout: 5s
      retries: 3
      start_period: 30s

  # Node.js dengan custom health script
  node-app:
    build: ./node-app
    healthcheck:
      test: ["CMD", "node", "healthcheck.js"]
      interval: 30s
      timeout: 10s
      retries: 3
      start_period: 20s

  # Elasticsearch
  elasticsearch:
    image: elasticsearch:8.10.0
    healthcheck:
      test: ["CMD-SHELL", "curl -s http://localhost:9200/_cluster/health | grep -q '\"status\":\"green\"\\|\"status\":\"yellow\"'"]
      interval: 30s
      timeout: 10s
      retries: 5
      start_period: 60s

services:
  api:
    build: ./backend
    depends_on:
      # Tunggu sampai postgres benar-benar sehat
      postgres:
        condition: service_healthy
      # Tunggu sampai redis benar-benar sehat
      redis:
        condition: service_healthy
      # Tunggu sampai migrasi selesai (service_started + exit)
      migrate:
        condition: service_completed_successfully

  # Database migration (berjalan sekali lalu exit)
  migrate:
    build: ./backend
    command: ["npm", "run", "migrate"]
    environment:
      - DATABASE_URL=postgresql://user:${DB_PASSWORD}@postgres:5432/appdb
    depends_on:
      postgres:
        condition: service_healthy
    profiles:
      - migration

# Cek status health semua container
docker compose ps
# NAME          STATUS                    PORTS
# app-api       Up 5 min (healthy)        0.0.0.0:4000->4000/tcp
# app-db        Up 5 min (healthy)        5432/tcp
# app-redis     Up 5 min (healthy)        6379/tcp

# Detail health check dari satu container
docker inspect --format='{{json .State.Health}}' app-api | jq

# Log health check history
docker inspect --format='{{range .State.Health.Log}}{{.Output}}{{end}}' app-api

services:
  worker:
    build: ./worker
    # Jangan hardcode container_name jika ingin scale!
    # container_name: app-worker   ← JANGAN ini
    environment:
      - REDIS_URL=redis://redis:6379
      - WORKER_CONCURRENCY=4
    deploy:
      replicas: 3
      resources:
        limits:
          cpus: '0.50'
          memory: 256M
        reservations:
          cpus: '0.25'
          memory: 128M
      restart_policy:
        condition: on-failure
        delay: 5s
        max_attempts: 3
        window: 120s

# Scale worker menjadi 5 instance
docker compose up -d --scale worker=5

# Scale API menjadi 3 instance
docker compose up -d --scale api=3

# Perhatikan: port binding akan conflict jika di-scale!
# Solusi: gunakan range port atau Nginx load balancer
# ports:
#   - "4000-4010:4000"    ← assign port otomatis

# Struktur file:
# docker-compose.yml          ← Base config
# docker-compose.override.yml ← Auto-loaded, untuk development
# docker-compose.prod.yml     ← Production overrides
# docker-compose.test.yml     ← Testing overrides

# Development (auto-load base + override)
docker compose up -d

# Production (base + prod override)
docker compose -f docker-compose.yml -f docker-compose.prod.yml up -d

# Testing (base + test override)
docker compose -f docker-compose.yml -f docker-compose.test.yml up -d

# docker-compose.prod.yml — Production overrides
services:
  api:
    restart: always
    logging:
      driver: json-file
      options:
        max-size: "10m"
        max-file: "3"
    environment:
      - NODE_ENV=production
      - LOG_LEVEL=warn

  nginx:
    restart: always
    logging:
      driver: json-file
      options:
        max-size: "5m"
        max-file: "5"

  postgres:
    restart: always
    command: >
      postgres
        -c shared_buffers=256MB
        -c effective_cache_size=768MB
        -c maintenance_work_mem=64MB
        -c work_mem=4MB
        -c max_connections=200
    logging:
      driver: json-file
      options:
        max-size: "10m"
        max-file: "5"

services:
  api:
    build: ./backend
    # Read-only root filesystem
    read_only: true
    # tmpfs untuk directory yang perlu write
    tmpfs:
      - /tmp
      - /app/tmp
    # Non-root user
    user: "1000:1000"
    # Drop capabilities
    cap_drop:
      - ALL
    cap_add:
      - NET_BIND_SERVICE    # Hanya jika perlu bind port < 1024
    # Security options
    security_opt:
      - no-new-privileges:true
    # Batasi PID (mencegah fork bomb)
    pids_limit: 100

  postgres:
    image: postgres:16
    read_only: true
    tmpfs:
      - /tmp
      - /run/postgresql
    cap_drop:
      - ALL
    cap_add:
      - CHOWN
      - DAC_OVERRIDE
      - FOWNER
      - SETGID
      - SETUID
    security_opt:
      - no-new-privileges:true

# ===========================
# DIAGNOSTICS
# ===========================

# Cek status semua service
docker compose ps -a

# Lihat log dengan timestamp
docker compose logs -f -t api

# Lihat log 100 baris terakhir
docker compose logs --tail 100 api

# Resource usage (CPU, memory, network)
docker compose top
docker stats --no-stream

# Inspect service configuration (resolved)
docker compose config

# Validasi compose file tanpa menjalankan
docker compose config --quiet

# ===========================
# DEBUGGING CONTAINER
# ===========================

# Masuk ke container yang sedang berjalan
docker compose exec api /bin/sh

# Jalankan command satu kali
docker compose exec api env

# Masuk ke container baru (tidak ke yang running)
docker compose run --rm api /bin/sh

# ===========================
# NETWORK DEBUGGING
# ===========================

# List networks
docker network ls

# Inspect network
docker network inspect myapp_frontend

# Tes koneksi antar container
docker compose exec api ping postgres
docker compose exec api nc -zv postgres 5432

# ===========================
# CLEANUP
# ===========================

# Hapus stopped containers
docker compose rm -f

# Hapus images yang tidak digunakan
docker image prune -f

# Hapus semua unused resources
docker system prune -f --volumes
