CoAP Protocol untuk IoT

┌─────────────────────────────────────┐
│         CoAP (Application)          │  ← RFC 7252
├─────────────────────────────────────┤
│              UDP                    │  ← Transport
├─────────────────────────────────────┤
│         IPv6 / 6LoWPAN              │  ← Network
├─────────────────────────────────────┤
│      IEEE 802.15.4 / BLE           │  ← Link
└─────────────────────────────────────┘

 0                   1                   2                   3
 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|Ver| T |  TKL  |      Code     |         Message ID            |
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|   Token (0-8 bytes, sesuai TKL) ...
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|   Options ...
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
|1 1 1 1 1 1 1 1|    Payload (jika ada) ...
+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+

Ver   = Version (2 bit, selalu 01 untuk CoAP v1)
T     = Type (2 bit: CON=0, NON=1, ACK=2, RST=3)
TKL   = Token Length (4 bit: 0-8 bytes)
Code  = Request/Response code (8 bit)
MsgID = Message ID (16 bit, untuk deduplikasi)

# Contoh CoAP URIs
coap://sensor.example.com/temperature
coap://[::1]:5683/led/status
coaps://gateway.local/humidity

# Content-Format Codes (IANA registered)
0   - text/plain; charset=utf-8
40  - application/link-format
41  - application/xml
42  - application/octet-stream
47  - application/exi
50  - application/json
60  - application/cbor

# Success Responses (2.xx)
2.01 - Created
2.02 - Deleted
2.03 - Valid (cache masih valid)
2.04 - Changed
2.05 - Content (equivalent HTTP 200 OK)

# Client Error Responses (4.xx)
4.00 - Bad Request
4.01 - Unauthorized
4.02 - Bad Option
4.03 - Forbidden
4.04 - Not Found
4.05 - Method Not Allowed
4.06 - Not Acceptable
4.08 - Request Entity Incomplete
4.12 - Precondition Failed
4.13 - Request Entity Too Large
4.15 - Unsupported Content-Format

# Server Error Responses (5.xx)
5.00 - Internal Server Error
5.01 - Not Implemented
5.02 - Bad Gateway
5.03 - Service Unavailable
5.04 - Gateway Timeout

# === Skenario: Client membaca sensor suhu ===

Client                                          Server
  |                                               |
  |--- CON [0x7a21] GET /temperature  -------->   |
  |                                               |
  |<-- ACK [0x7a21] 2.05 Content {"temp":23.5}   |
  |                                               |

# === Skenario: Multicast discovery ===

Client (multicast ke ff02::1)                     Server A & B
  |                                               |
  |--- NON [0x7a22] GET /.well-known/core ------->|
  |                                               |
  |<-- NON [0x7a22] 2.05 Content [A's resources]  |
  |<-- NON [0x7a22] 2.05 Content [B's resources]  |

# === Skenario: Reliable messaging dengan retransmit ===

Client                                          Server
  |                                               |
  |--- CON [0x1234] PUT /led  Payload: "on" --->  |
  |    (timeout, no ACK received)                 |
  |--- CON [0x1234] PUT /led  Payload: "on" --->  | (retransmit)
  |                                               |
  |<-- ACK [0x1234] 2.04 Changed                  |

# Client mendaftar sebagai observer dengan menambahkan Observe option

Client                                          Server
  |                                               |
  |--- CON [0x7a21] GET /temperature              |
  |    Observe: 0 (register)  ----------------->  |
  |                                               |
  |<-- ACK [0x7a21] 2.05 Content                  |
  |    Observe: 1   {"temp": 23.5}                |
  |                                               |
  |    ... suhu berubah ...                       |
  |                                               |
  |<-- CON [0x7a22] 2.05 Content                  |
  |    Observe: 2   {"temp": 24.1}                |
  |--- ACK [0x7a22]  ---------------------------> |
  |                                               |
  |    ... suhu berubah lagi ...                  |
  |                                               |
  |<-- NON [0x7a23] 2.05 Content                  |
  |    Observe: 3   {"temp": 23.8}                |
  |                                               |

import asyncio
from aiocoap import *

async def observe_temperature():
    """Register sebagai observer pada resource /temperature"""
    protocol = await Context.create_client_context()

    request = Message(
        code=GET,
        uri='coap://sensor.example.com/temperature',
        observe=0  # Register sebagai observer
    )

    # Kirim request pertama dan dapatkan initial response
    requester = protocol.request(request)
    first_response = await requester.response
    print(f"Suhu awal: {first_response.payload.decode()}")

    # Loop untuk menerima notifikasi berikutnya
    async for response in requester.observation:
        print(f"Suhu berubah: {response.payload.decode()}")

        # Unsubscribe jika sudah tidak perlu
        if float(response.payload.decode()) > 30.0:
            requester.observation.cancel()
            break

asyncio.run(observe_temperature())

# Block Option encoding (variable length: 1-3 bytes)
# Format: NUM.M.SIZE
#
# NUM  = Block number (4/12/20 bit) — sequential numbering
# M    = More bit (1 bit) — 1 jika ada blok berikutnya, 0 jika terakhir
# SIZE = Block size exponent (3 bit) — 2^(4+SZX) bytes
#
# Block Size mapping:
# SZX=0 → 16 bytes    SZX=4 → 256 bytes
# SZX=1 → 32 bytes    SZX=5 → 512 bytes
# SZX=2 → 64 bytes    SZX=6 → 1024 bytes
# SZX=3 → 128 bytes   SZX=7 → reserved

# Contoh transfer file 1024 bytes dengan block size 256 bytes:
# Block 0: NUM=0, M=1, SZX=4  → "0M4" = bytes 0-255
# Block 1: NUM=1, M=1, SZX=4  → "1M4" → bytes 256-511
# Block 2: NUM=2, M=1, SZX=4  → "2M4" → bytes 512-767
# Block 3: NUM=3, M=0, SZX=4  → "3_4" → bytes 768-1023 (terakhir)

Client                                          Server
  |                                               |
  |--- CON GET /firmware                         |
  |    Block2: 0/0/6 (NUM=0, M=0, SZX=6) --->   |
  |    (minta blok pertama, size 1024)            |
  |                                               |
  |<-- ACK 2.05 Content                           |
  |    Block2: 0/1/6 (M=1, ada lagi)             |
  |    [bytes 0-1023]                             |
  |                                               |
  |--- CON GET /firmware                         |
  |    Block2: 1/0/6  ----------------------->   |
  |                                               |
  |<-- ACK 2.05 Content                           |
  |    Block2: 1/1/6                             |
  |    [bytes 1024-2047]                          |
  |                                               |
  |--- CON GET /firmware                         |
  |    Block2: 2/0/6  ----------------------->   |
  |                                               |
  |<-- ACK 2.05 Content                           |
  |    Block2: 2/0/6 (M=0, selesai)              |
  |    [bytes 2048-3000]                          |

import asyncio
from aiocoap import *
from aiocoap.numbers import ContentFormat

async def upload_firmware():
    """Upload firmware menggunakan Block1 transfer"""
    context = await Context.create_client_context()

    firmware_data = open('firmware.bin', 'rb').read()
    block_size = 1024
    total_blocks = (len(firmware_data) + block_size - 1) // block_size

    for i in range(total_blocks):
        start = i * block_size
        end = min(start + block_size, len(firmware_data))
        chunk = firmware_data[start:end]

        request = Message(
            code=PUT,
            uri='coap://device.local/firmware',
            payload=chunk,
            content_format=ContentFormat.OCTETSTREAM
        )

        # Set Block1 option: NUM/M/SZX
        is_last = (i == total_blocks - 1)
        request.remote.opt.block1 = (i, not is_last, 6)

        response = await context.request(request).response
        print(f"Block {i+1}/{total_blocks}: {response.code}")

    print("Upload selesai!")

asyncio.run(upload_firmware())

# DTLS 1.2 Handshake (mirip TLS tetapi di atas UDP)

Client (IoT Device)                    Server (Gateway)
  |                                        |
  |--- ClientHello  --------------------> |
  |<-- HelloVerifyRequest (cookie)        |
  |--- ClientHello + Cookie  -----------> |
  |<-- ServerHello + Certificate          |
  |<-- ServerKeyExchange                  |
  |<── ServerHelloDone                    |
  |--- ClientKeyExchange                  |
  |--- ChangeCipherSpec                   |
  |--- Finished  ────────────────────────>|
  |<── ChangeCipherSpec                   |
  |<── Finished                           |
  |                                        |
  |==== Encrypted CoAP messages =========>|

import asyncio
from aiocoap import *

async def secure_request():
    """Mengirim CoAP request dengan DTLS (PreSharedKey)"""
    context = await Context.create_client_context()

    # Setup DTLS credentials
    # Untuk PSK, client dan server harus share identity + key
    # Implementation-specific setup via aiocoap credentials
    request = Message(
        code=GET,
        uri='coaps://gateway.example.com:5684/sensors/data'
    )

    response = await context.request(request).response
    print(f"Status: {response.code}")
    print(f"Data: {response.payload.decode()}")

asyncio.run(secure_request())

import asyncio
import json
import datetime
import aiocoap
import aiocoap.resource as resource

class TemperatureResource(resource.ObservableResource):
    """Resource /temperature dengan Observe support"""
    def __init__(self):
        super().__init__()
        self.temperature = 23.5
        self.notify()

    def notify(self):
        self.updated_state()
        # Schedule next update setiap 10 detik
        asyncio.get_event_loop().call_later(10, self.notify)

    async def render_get(self, request):
        data = json.dumps({
            "temperature": self.temperature,
            "unit": "celsius",
            "timestamp": datetime.datetime.now().isoformat()
        })
        return aiocoap.Message(
            payload=data.encode('utf-8'),
            content_format=50  # application/json
        )

    async def render_put(self, request):
        """Update temperature via PUT"""
        payload = json.loads(request.payload.decode())
        self.temperature = payload.get("temperature", self.temperature)
        return aiocoap.Message(
            code=aiocoap.CHANGED,
            payload=json.dumps({"status": "ok"}).encode()
        )

class DeviceInfoResource(resource.Resource):
    """Resource /info — static device information"""
    async def render_get(self, request):
        info = {
            "device": "ESP32-Sensor-01",
            "firmware": "1.2.3",
            "uptime": "24h 30m",
            "battery": "87%"
        }
        return aiocoap.Message(
            payload=json.dumps(info).encode(),
            content_format=50
        )

# Build resource tree
root = resource.Site()
root.add_resource(['temperature'], TemperatureResource())
root.add_resource(['info'], DeviceInfoResource())
root.add_resource(['.well-known', 'core'],
    resource.WKCResource(root.get_resources_as_linkheader))

# Start CoAP server
asyncio.Task(aiocoap.Context.create_server_context(root))
asyncio.get_event_loop().run_forever()

#include <WiFi.h>
#include <WiFiUdp.h>
#include <coap-simple.h>

const char* ssid = "MyNetwork";
const char* password = "MyPassword";

WiFiUDP udp;
Coap coap(udp);

// Callback saat menerima response
void callback_response(CoapPacket &packet, IPAddress ip, int port) {
    char p[packet.payloadlen + 1];
    memcpy(p, packet.payload, packet.payloadlen);
    p[packet.payloadlen] = '\0';

    Serial.print("Response dari ");
    Serial.print(ip);
    Serial.print(": ");
    Serial.println(p);
}

void setup() {
    Serial.begin(115200);
    WiFi.begin(ssid, password);

    while (WiFi.status() != WL_CONNECTED) {
        delay(500);
        Serial.print(".");
    }
    Serial.println("WiFi connected!");

    // Register response callback
    coap.response(callback_response);

    // Start CoAP client
    coap.start();

    // Kirim GET request ke server CoAP
    coap.get(IPAddress(192, 168, 1, 100), 5683, "temperature");
}

void loop() {
    coap.loop();

    // Kirim request setiap 30 detik
    static unsigned long lastTime = 0;
    if (millis() - lastTime > 30000) {
        lastTime = millis();
        coap.get(IPAddress(192, 168, 1, 100), 5683, "temperature");
    }
}
