Chaos Engineering with Litmus

# Tambahkan Helm repo
helm repo add litmuschaos https://litmuschaos.github.io/litmus-helm/
helm repo update

# Install Litmus Control Plane (ChaosCenter)
helm install litmus litmuschaos/litmus-control-plane \
  --namespace litmus --create-namespace \
  --set portal.frontend.service.type=NodePort

# Atau install hanya CRDs + Operator (tanpa UI)
helm install litmus litmuschaos/litmus \
  --namespace litmus --create-namespace

# Verifikasi instalasi
kubectl get pods -n litmus
# NAME                                    READY   STATUS
# litmus-server-xxx                       1/1     Running
# litmus-frontend-xxx                     1/1     Running
# litmus-mongo-xxx                        1/1     Running
# chaos-operator-ce-xxx                   1/1     Running

# Akses ChaosCenter UI
kubectl port-forward svc/litmusportal-frontend -n litmus 3030:80
# Buka http://localhost:3030
# Default credentials: admin / litmus

# Install litmusctl CLI
curl -sL https://litmusctl.litmuschaos.io/install.sh | bash
# Atau download dari GitHub releases

# Login via CLI
litmusctl config set-account --endpoint="http://localhost:3030" \
  --username="admin" --password="litmus"

# ServiceAccount dan RBAC untuk chaos experiments
apiVersion: v1
kind: ServiceAccount
metadata:
  name: litmus-admin
  namespace: litmus

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRole
metadata:
  name: litmus-admin
rules:
  - apiGroups: [""]
    resources: ["pods", "pods/exec", "pods/log", "events", "services",
      "configmaps", "secrets", "persistentvolumeclaims"]
    verbs: ["create", "delete", "get", "list", "patch", "update"]
  - apiGroups: ["apps"]
    resources: ["deployments", "statefulsets", "daemonsets"]
    verbs: ["create", "delete", "get", "list", "patch", "update"]
  - apiGroups: ["litmuschaos.io"]
    resources: ["*"]
    verbs: ["*"]
  - apiGroups: ["batch"]
    resources: ["jobs"]
    verbs: ["create", "delete", "get", "list"]
  - apiGroups: [""]
    resources: ["nodes"]
    verbs: ["get", "list"]

---
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: litmus-admin
roleRef:
  apiGroup: rbac.authorization.k8s.io
  kind: ClusterRole
  name: litmus-admin
subjects:
  - kind: ServiceAccount
    name: litmus-admin
    namespace: litmus

# Install eksperimen dari ChaosHub
# litmusctl get chaos-experiments --hub-name=ChaosHub

# Atau install manual
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: pod-delete-engine
  namespace: default
spec:
  # Target aplikasi
  appinfo:
    appns: default
    applabel: app=my-app
    appkind: deployment

  # ServiceAccount yang digunakan
  serviceAccount: litmus-admin

  # Experiments yang akan dijalankan
  experiments:
    - name: pod-delete
      spec:
        components:
          env:
            # Jumlah pod yang akan di-delete
            - name: TOTAL_CHAOS_DURATION
              value: '30'
            # Interval antara pod deletion
            - name: CHAOS_INTERVAL
              value: '10'
            # Force delete (tanpa graceful termination)
            - name: FORCE
              value: 'false'
            # Target pod count
            - name: TARGET_PODS
              value: ''
            # Pod affected percentage
            - name: PODS_AFFECTED_PERC
              value: ''
        # Probes untuk verifikasi
        probes:
          - name: "Verify app is running"
            type: "httpProbe"
            mode: "Continuous"
            httpProbe/inputs:
              url: "http://my-app.default.svc:8080/health"
              method:
                get:
                  criteria: "=="
                  responseCode: "200"
            runProperties:
              probeTimeout: 5
              interval: 2
              retry: 3

  # Experiment execution policy
  engineState: "active"
  chaosServiceAccount: litmus-admin

# Install eksperimen spesifik ke cluster
kubectl apply -f https://hub.litmuschaos.io/api/chaos/1.13.0?file=charts/generic/experiments.yaml

# Kategori eksperimen yang tersedia di ChaosHub:

# === Kubernetes Faults ===
# pod-delete        — Hapus pods secara acak
# pod-cpu-hog       — Stress CPU pada pods
# pod-memory-hog    — Exhaust memory pada pods
# pod-network-loss  — Simulasikan packet loss
# pod-network-delay — Tambahkan network latency
# pod-dns-error     — Simulasikan DNS failures

# === Application Faults ===
# node-drain        — Drain node dari pods
# node-cpu-hog     — Stress CPU pada node
# node-memory-hog  — Exhaust memory node
# node-taint       — Taint nodes
# kubelet-service-kill — Kill kubelet service

# === Cloud Provider Faults ===
# ec2-terminate     — Terminate EC2 instances
# ebs-loss          — Detach EBS volumes
# gcp-vm-stop       — Stop GCP VM instances
# azure-vm-stop     — Stop Azure VM instances

# === Network Faults ===
# network-partition — Simulasikan network partition
# network-duplication — Duplicate network packets
# network-jitter    — Add network jitter
# bandwidth-limit   — Limit network bandwidth

# Install eksperimen spesifik
kubectl apply -f https://hub.litmuschaos.io/api/chaos/1.13.0?file=charts/generic/experiments.yaml -n litmus

# Cek eksperimen yang terinstall
kubectl get chaosexperiments -n litmus

apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: network-delay-engine
  namespace: default
spec:
  appinfo:
    appns: default
    applabel: app=api-gateway
    appkind: deployment
  experiments:
    - name: pod-network-delay
      spec:
        components:
          env:
            - name: NETWORK_LATENCY
              value: '2000'  # 2 detik delay
            - name: JITTER
              value: '500'   # 500ms jitter
            - name: DESTINATION_IPS
              value: ''      # Semua IPs
            - name: DESTINATION_HOSTS
              value: ''      # Semua hosts
            - name: CONTAINER_RUNTIME
              value: 'containerd'
            - name: TOTAL_CHAOS_DURATION
              value: '60'
            - name: CHAOS_INTERVAL
              value: '10'
        probes:
          - name: "Verify latency is bounded"
            type: "promProbe"
            mode: "Edge"
            promProbe/inputs:
              endpoint: "http://prometheus.monitoring:9090"
              query: |
                histogram_quantile(0.99,
                  sum(rate(http_request_duration_seconds_bucket[1m]))) < 5
              comparator:
                type: "float"
                criteria: "<"
                value: "5"
            runProperties:
              probeTimeout: 10
              interval: 5

# Probes di dalam ChaosEngine experiment spec
experiments:
  - name: pod-delete
    spec:
      probes:
        # Probe 1: HTTP health check (continuous)
        - name: "App is responding"
          type: "httpProbe"
          mode: "Continuous"
          httpProbe/inputs:
            url: "http://my-app.default:8080/health"
            method:
              get:
                criteria: "=="
                responseCode: "200"
          runProperties:
            probeTimeout: 5
            interval: 2
            retry: 3
            probePollingInterval: 2

        # Probe 2: K8s resource validation (edge)
        - name: "Deployment has minimum replicas"
          type: "k8sProbe"
          mode: "Edge"
          k8sProbe/inputs:
            command:
              command: ["kubectl", "get", "deploy", "my-app",
                "-o", "jsonpath='{.status.readyReplicas}'"]
            comparator:
              type: "int"
              criteria: ">="
              value: "2"
          runProperties:
            probeTimeout: 10

        # Probe 3: Prometheus metric validation (edge)
        - name: "Error rate below threshold"
          type: "promProbe"
          mode: "Edge"
          promProbe/inputs:
            endpoint: "http://prometheus.monitoring:9090"
            query: |
              sum(rate(http_requests_total{status=~"5.."}[2m]))
              / sum(rate(http_requests_total[2m])) * 100
            comparator:
              type: "float"
              criteria: "<"
              value: "5"
          runProperties:
            probeTimeout: 15
            interval: 10

        # Probe 4: Command validation (onChaos)
        - name: "DB connection exists"
          type: "cmdProbe"
          mode: "OnChaos"
          cmdProbe/inputs:
            command: "pg_isready -h postgres.default -p 5432"
            comparator:
              type: "string"
              criteria: "contains"
              value: "accepting"
          runProperties:
            probeTimeout: 10

# ChaosEngine lengkap dengan multiple experiments
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosEngine
metadata:
  name: comprehensive-resilience-test
  namespace: default
  labels:
    app.kubernetes.io/part-of: resilience-testing
    environment: staging
spec:
  engineState: active
  chaosServiceAccount: litmus-admin
  appinfo:
    appns: default
    applabel: app=my-app,env=staging
    appkind: deployment

  experiments:
    # Experiment 1: Pod Delete
    - name: pod-delete
      spec:
        components:
          env:
            - name: TOTAL_CHAOS_DURATION
              value: '30'
            - name: CHAOS_INTERVAL
              value: '10'
            - name: FORCE
              value: 'false'
        probes:
          - name: "App recovers after pod delete"
            type: "httpProbe"
            mode: "Edge"
            httpProbe/inputs:
              url: "http://my-app:8080/health"
              method:
                get:
                  criteria: "=="
                  responseCode: "200"
            runProperties:
              probeTimeout: 30
              interval: 5
              retry: 10

    # Experiment 2: CPU Stress
    - name: pod-cpu-hog
      spec:
        components:
          env:
            - name: CPU_CORES
              value: '2'
            - name: CPU_LOAD
              value: '100'
            - name: TOTAL_CHAOS_DURATION
              value: '60'
        probes:
          - name: "Latency still acceptable under CPU pressure"
            type: "promProbe"
            mode: "Edge"
            promProbe/inputs:
              endpoint: "http://prometheus.monitoring:9090"
              query: |
                histogram_quantile(0.99,
                  sum(rate(http_request_duration_seconds_bucket[1m]))) < 2
              comparator:
                type: "float"
                criteria: "<"
                value: "2"

    # Experiment 3: Network Loss
    - name: pod-network-loss
      spec:
        components:
          env:
            - name: NETWORK_PACKET_LOSS_PERCENTAGE
              value: '30'
            - name: DESTINATION_IPS
              value: ''
            - name: DESTINATION_HOSTS
              value: ''
            - name: CONTAINER_RUNTIME
              value: 'containerd'
            - name: TOTAL_CHAOS_DURATION
              value: '60'
        probes:
          - name: "App handles packet loss gracefully"
            type: "k8sProbe"
            mode: "Edge"
            k8sProbe/inputs:
              command:
                command: ["kubectl", "get", "deploy", "my-app",
                  "-o", "jsonpath='{.status.readyReplicas}'"]
              comparator:
                type: "int"
                criteria: ">="
                value: "1"

  # Schedule — jalankan eksperimen secara periodik
  schedule:
    repeat: weekly
    time: "02:00"  # Jam 2 pagi
    dayOfWeek: "Saturday"

  # Rollback jika probes gagal
  jobCleanUpPolicy: delete

# Formula Resilience Score
# RS = (Jumlah probe yang passed / Total probes) × 100

# Contoh: ChaosEngine dengan 3 experiments
# Experiment 1 (pod-delete): 2/3 probes passed → 66.7%
# Experiment 2 (cpu-stress): 3/3 probes passed → 100%
# Experiment 3 (net-loss): 1/3 probes passed → 33.3%

# Overall Resilience Score = (66.7 + 100 + 33.3) / 3 = 66.7%

# Ambil hasil dari ChaosResult CRD
# kubectl get chaosresult -n default -o yaml
apiVersion: litmuschaos.io/v1alpha1
kind: ChaosResult
metadata:
  name: pod-delete-pod-delete
  namespace: default
spec:
  engine: comprehensive-resilience-test
  experiment: pod-delete
status:
  experimentStatus:
    phase: Completed
    verdict: Pass
    probeSuccessPercentage: "66.7"
    runningPhase: Completed
  # History dari setiap run
  history:
    - verdict: Pass
      probeSuccessPercentage: "66.7"
      updatedAt: "2026-06-29T02:15:00Z"
    - verdict: Fail
      probeSuccessPercentage: "33.3"
      updatedAt: "2026-06-22T02:15:00Z"

# Monitoring resilience score di Grafana
# PromQL query untuk Litmus metrics
# litmus_experiment_verdict{experiment="pod-delete"}
# litmus_probe_success_percentage

# Target resilience score per environment:
# Development: 60%+ (acceptable)
# Staging: 80%+ (good)
# Production: 90%+ (excellent)

# .github/workflows/chaos-test.yml
name: Chaos Engineering Test

on:
  pull_request:
    branches: [main]
  schedule:
    - cron: '0 2 * * 6'  # Setiap Sabtu jam 2 pagi

jobs:
  chaos-test:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup Kubernetes cluster
        uses: helm/kind-action@v1

      - name: Install Litmus
        run: |
          helm repo add litmuschaos https://litmuschaos.github.io/litmus-helm/
          helm install litmus litmuschaos/litmus \
            --namespace litmus --create-namespace

      - name: Deploy application
        run: kubectl apply -f k8s/

      - name: Run chaos experiments
        run: |
          kubectl apply -f chaos/pod-delete.yaml
          # Tunggu eksperimen selesai
          kubectl wait --for=condition=Completed \
            chaosresult/pod-delete-pod-delete \
            --timeout=300s

      - name: Check resilience score
        run: |
          SCORE=$(kubectl get chaosresult -o jsonpath=
            '{.items[0].status.experimentStatus.probeSuccessPercentage}')
          echo "Resilience Score: $SCORE%"
          if (( $(echo "$SCORE < 80" | bc -l) )); then
            echo "❌ Resilience score below threshold!"
            exit 1
          fi
          echo "✅ Resilience check passed"
