Ansible: Automation Platform

# Tambah PPA repository
sudo apt update
sudo apt install -y software-properties-common
sudo add-apt-repository --yes --update ppa:ansible/ansible

# Install Ansible
sudo apt install -y ansible

# Verifikasi
ansible --version
# ansible [core 2.17.0]
#   config file = /etc/ansible/ansible.cfg
#   python version = 3.12.3

# Fedora
sudo dnf install -y ansible

# RHEL/CentOS
sudo yum install -y epel-release
sudo yum install -y ansible

# Install menggunakan Homebrew
brew install ansible

# Verifikasi
ansible --version

# Install dengan pip (Python package manager)
pip install ansible

# Install dengan pipx (isolated environment)
pip install pipx
pipx install ansible

# Install specific version
pip install ansible==9.5.1

# Install collections dan roles
ansible-galaxy collection install community.general
ansible-galaxy install geerlingguy.nginx

# Generate SSH key pair
ssh-keygen -t ed25519 -C "ansible@beebanelabs" -f ~/.ssh/ansible_key

# Copy public key ke target servers
ssh-copy-id -i ~/.ssh/ansible_key.pub user@server1
ssh-copy-id -i ~/.ssh/ansible_key.pub user@server2
ssh-copy-id -i ~/.ssh/ansible_key.pub user@server3

# Test koneksi
ssh -i ~/.ssh/ansible_key user@server1 "echo OK"

# inventory/hosts.ini
# === Server Web ===
web1 ansible_host=192.168.1.10 ansible_user=deploy
web2 ansible_host=192.168.1.11 ansible_user=deploy
web3 ansible_host=192.168.1.12 ansible_user=deploy

# === Server Database ===
db1 ansible_host=192.168.1.20 ansible_user=dbadmin ansible_port=2222
db2 ansible_host=192.168.1.21 ansible_user=dbadmin ansible_port=2222

# === Server Cache ===
redis1 ansible_host=192.168.1.30 ansible_user=deploy

# === Server Monitoring ===
monitor1 ansible_host=192.168.1.40 ansible_user=admin

# === Groups ===
[webservers]
web1
web2
web3

[dbservers]
db1
db2

[cacheservers]
redis1

[monitoring]
monitor1

# === Group of Groups (Parent Group) ===
[production:children]
webservers
dbservers
cacheservers
monitoring

# === Group Variables ===
[webservers:vars]
http_port=80
https_port=443
nginx_version=1.27.0

[dbservers:vars]
mysql_port=3306
mysql_datadir=/var/lib/mysql

[all:vars]
ansible_python_interpreter=/usr/bin/python3
ansible_ssh_common_args='-o StrictHostKeyChecking=no'

# inventory/hosts.yaml
all:
  vars:
    ansible_python_interpreter: /usr/bin/python3
    ansible_ssh_common_args: '-o StrictHostKeyChecking=no'
  children:
    production:
      children:
        webservers:
          hosts:
            web1:
              ansible_host: 192.168.1.10
              ansible_user: deploy
            web2:
              ansible_host: 192.168.1.11
              ansible_user: deploy
            web3:
              ansible_host: 192.168.1.12
              ansible_user: deploy
          vars:
            http_port: 80
            https_port: 443
            nginx_version: "1.27.0"

        dbservers:
          hosts:
            db1:
              ansible_host: 192.168.1.20
              ansible_user: dbadmin
              ansible_port: 2222
            db2:
              ansible_host: 192.168.1.21
              ansible_user: dbadmin
              ansible_port: 2222
          vars:
            mysql_port: 3306

        cacheservers:
          hosts:
            redis1:
              ansible_host: 192.168.1.30
              ansible_user: deploy

        monitoring:
          hosts:
            monitor1:
              ansible_host: 192.168.1.40
              ansible_user: admin

# List semua host
ansible-inventory -i inventory/hosts.yaml --list

# List host dalam format grafik
ansible-inventory -i inventory/hosts.yaml --graph

# List host dari group tertentu
ansible-inventory -i inventory/hosts.yaml --graph webservers

# List semua group
ansible-inventory -i inventory/hosts.yaml --list --yaml

# Verifikasi koneksi ke semua host
ansible all -i inventory/hosts.yaml -m ping

# Verifikasi koneksi ke group tertentu
ansible webservers -i inventory/hosts.yaml -m ping

# Sintaks umum
ansible <target> -m <module> -a "<args>" -i <inventory>

# Contoh: ping semua host
ansible all -m ping -i inventory/hosts.yaml
# web1 | SUCCESS => {"changed": false, "ping": "pong"}
# web2 | SUCCESS => {"changed": false, "ping": "pong"}
# db1  | SUCCESS => {"changed": false, "ping": "pong"}

# Jalankan command shell di semua host
ansible all -m command -a "uptime" -i inventory/hosts.yaml
ansible all -m shell -a "df -h" -i inventory/hosts.yaml

# Lihat info sistem
ansible all -m setup -i inventory/hosts.yaml
ansible all -m setup -a "filter=ansible_distribution" -i inventory/hosts.yaml

# Install package di semua web servers
ansible webservers -m apt -a "name=nginx state=present" \
  -i inventory/hosts.yaml --become

# Restart service nginx
ansible webservers -m service -a "name=nginx state=restarted" \
  -i inventory/hosts.yaml --become

# Copy file ke semua servers
ansible webservers -m copy \
  -a "src=./config/nginx.conf dest=/etc/nginx/nginx.conf mode=0644" \
  -i inventory/hosts.yaml --become

# Buat user baru
ansible all -m user \
  -a "name=deploy state=present shell=/bin/bash" \
  -i inventory/hosts.yaml --become

# Cek disk space
ansible all -m shell -a "df -h /" -i inventory/hosts.yaml

# Cek memory usage
ansible all -m shell -a "free -m" -i inventory/hosts.yaml

# Tambah SSH authorized key
ansible all -m authorized_key \
  -a "user=deploy key='{{ lookup(\"file\", \"~/.ssh/ansible_key.pub\") }}'" \
  -i inventory/hosts.yaml

# Jalankan dengan parallel (fork 10)
ansible all -m ping -i inventory/hosts.yaml -f 10

# Jalankan dengan sudo (--become)
ansible webservers -m shell -a "apt update" \
  -i inventory/hosts.yaml --become

# Jalankan dengan specific user
ansible webservers -m ping -i inventory/hosts.yaml \
  -u deploy --private-key ~/.ssh/ansible_key

# playbooks/setup-webserver.yaml
---
- name: Setup Web Server          # Nama play
  hosts: webservers               # Target hosts
  become: yes                     # Gunakan sudo
  vars:                           # Variables untuk play ini
    nginx_version: "1.27.0"
    app_port: 8080
  tasks:                          # Daftar tasks
    - name: Update apt cache
      apt:
        update_cache: yes
        cache_valid_time: 3600

    - name: Install Nginx
      apt:
        name: "nginx={{ nginx_version }}"
        state: present

    - name: Copy Nginx config
      template:
        src: templates/nginx.conf.j2
        dest: /etc/nginx/nginx.conf
        owner: root
        group: root
        mode: '0644'
      notify: Restart Nginx

    - name: Ensure Nginx is running
      service:
        name: nginx
        state: started
        enabled: yes

    - name: Open firewall port
      ufw:
        rule: allow
        port: "{{ item }}"
        proto: tcp
      loop:
        - "22"
        - "80"
        - "443"

  handlers:                       # Handlers (triggered by notify)
    - name: Restart Nginx
      service:
        name: nginx
        state: restarted

# playbooks/full-stack.yaml
---
# Play 1: Setup Database Server
- name: Setup Database Server
  hosts: dbservers
  become: yes
  tasks:
    - name: Install MySQL
      apt:
        name:
          - mysql-server
          - mysql-client
          - python3-mysqldb
        state: present

    - name: Start MySQL
      service:
        name: mysql
        state: started
        enabled: yes

    - name: Create database
      mysql_db:
        name: "{{ app_db_name }}"
        state: present
        encoding: utf8mb4
        collation: utf8mb4_unicode_ci

    - name: Create database user
      mysql_user:
        name: "{{ app_db_user }}"
        password: "{{ app_db_password }}"
        priv: "{{ app_db_name }}.*:ALL"
        state: present

# Play 2: Setup Web Server
- name: Setup Web Server
  hosts: webservers
  become: yes
  vars:
    app_port: 8080
  tasks:
    - name: Install packages
      apt:
        name:
          - nginx
          - python3
          - python3-pip
          - certbot
          - python3-certbot-nginx
        state: present

    - name: Copy app config
      template:
        src: templates/app.conf.j2
        dest: /etc/nginx/sites-available/app.conf
      notify: Restart Nginx

    - name: Enable site
      file:
        src: /etc/nginx/sites-available/app.conf
        dest: /etc/nginx/sites-enabled/app.conf
        state: link
      notify: Restart Nginx

  handlers:
    - name: Restart Nginx
      service:
        name: nginx
        state: restarted

# Play 3: Setup Monitoring
- name: Setup Monitoring
  hosts: monitoring
  become: yes
  tasks:
    - name: Install Prometheus
      apt:
        name: prometheus
        state: present

    - name: Install Grafana
      apt:
        name: grafana
        state: present

# Error handling dengan block/rescue/always
- name: Deploy application with error handling
  hosts: webservers
  become: yes
  tasks:
    - block:
        - name: Pull latest code
          git:
            repo: "https://github.com/app/repo.git"
            dest: /opt/app
            version: main

        - name: Install dependencies
          command: pip install -r requirements.txt
          args:
            chdir: /opt/app

        - name: Restart application
          service:
            name: myapp
            state: restarted

      rescue:
        - name: Rollback to previous version
          git:
            repo: "https://github.com/app/repo.git"
            dest: /opt/app
            version: "{{ previous_version }}"

        - name: Send failure notification
          mail:
            to: admin@example.com
            subject: "Deploy FAILED on {{ inventory_hostname }}"
            body: "Deploy gagal, rolling back ke {{ previous_version }}"

      always:
        - name: Log deployment result
          lineinfile:
            path: /var/log/deployments.log
            line: "{{ ansible_date_time.iso8601 }} - Deploy attempted on {{ inventory_hostname }}"
            create: yes

# Jalankan playbook
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml

# Dry-run (check mode) — tanpa eksekusi
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml --check

# Verbose mode (-v, -vv, -vvv)
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml -vvv

# Jalankan dengan specific tag
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml --tags "nginx,firewall"

# Skip tags tertentu
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml --skip-tags "firewall"

# Jalankan dengan extra variables
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml \
  -e "nginx_version=1.27.1 app_port=9090"

# Limit ke host tertentu
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml \
  --limit web1,web2

# Step-by-step (konfirmasi setiap task)
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml --step

# Mulai dari task tertentu
ansible-playbook -i inventory/hosts.yaml playbooks/setup-webserver.yaml \
  --start-at-task="Copy Nginx config"

# Module apt — install packages
- name: Install required packages
  apt:
    name:
      - nginx
      - python3
      - git
      - curl
    state: present
    update_cache: yes

# Module file — buat direktori
- name: Create app directory
  file:
    path: /opt/myapp
    state: directory
    owner: deploy
    group: deploy
    mode: '0755'

# Module git — clone repository
- name: Clone application repository
  git:
    repo: "https://github.com/app/repo.git"
    dest: /opt/myapp
    version: main
    force: yes

# Module template — render dan copy config
- name: Generate nginx config
  template:
    src: templates/nginx.conf.j2
    dest: /etc/nginx/sites-available/myapp.conf
    owner: root
    group: root
    mode: '0644'
  notify: Restart nginx

# Module service — manage service
- name: Ensure nginx is running
  service:
    name: nginx
    state: started
    enabled: yes

# Module user — buat user
- name: Create application user
  user:
    name: deploy
    shell: /bin/bash
    groups: sudo
    append: yes
    create_home: yes

# Module cron — tambah cron job
- name: Add backup cron job
  cron:
    name: "Database backup"
    minute: "0"
    hour: "2"
    job: "/opt/scripts/backup.sh >> /var/log/backup.log 2>&1"
    user: deploy

# Module lineinfile — edit file
- name: Set timezone
  lineinfile:
    path: /etc/environment
    regexp: "^TZ="
    line: "TZ=Asia/Jakarta"

# Definisi di playbook
- name: Configure web server
  hosts: webservers
  vars:
    app_name: "myapp"
    app_port: 8080
    app_env: "production"
    db_host: "192.168.1.20"
    max_clients: 200
  tasks:
    - name: Print variables
      debug:
        msg: "Deploying {{ app_name }} on port {{ app_port }}"

# Definisi di file terpisah
# group_vars/webservers.yaml
app_name: "myapp"
app_port: 8080
db_host: "192.168.1.20"

# group_vars/dbservers.yaml
mysql_root_password: "{{ vault_mysql_root_password }}"
mysql_datadir: "/var/lib/mysql"

# host_vars/web1.yaml
app_port: 9090   # Override untuk web1 saja

# Lihat semua facts dari host
# ansible web1 -m setup -i inventory/hosts.yaml

# Gunakan facts di playbook
- name: Print system info
  hosts: all
  tasks:
    - name: Show OS info
      debug:
        msg: "{{ ansible_distribution }} {{ ansible_distribution_version }}"

    - name: Show IP address
      debug:
        msg: "IP: {{ ansible_default_ipv4.address }}"

    - name: Show memory
      debug:
        msg: "RAM: {{ ansible_memtotal_mb }} MB"

    - name: Conditional berdasarkan OS
      apt:
        name: nginx
        state: present
      when: ansible_distribution == "Ubuntu"

    - name: Conditional berdasarkan versi
      yum:
        name: nginx
        state: present
      when: ansible_distribution == "CentOS" and ansible_distribution_major_version == "8"

# Simpan output task ke variable
- name: Check service status
  hosts: webservers
  tasks:
    - name: Check nginx status
      command: systemctl is-active nginx
      register: nginx_status
      ignore_errors: yes

    - name: Print status
      debug:
        msg: "Nginx status: {{ nginx_status.stdout }}"

    - name: Start nginx if not running
      service:
        name: nginx
        state: started
      when: nginx_status.rc != 0

    - name: Get disk usage
      command: df -h /
      register: disk_info

    - name: Print disk usage
      debug:
        msg: "{{ disk_info.stdout_lines }}"

# Simple loop
- name: Install multiple packages
  apt:
    name: "{{ item }}"
    state: present
  loop:
    - nginx
    - python3
    - git
    - curl

# Loop dengan dictionary
- name: Create multiple users
  user:
    name: "{{ item.name }}"
    groups: "{{ item.groups }}"
    shell: "{{ item.shell }}"
  loop:
    - { name: "deploy", groups: "sudo", shell: "/bin/bash" }
    - { name: "monitor", groups: "adm", shell: "/bin/bash" }
    - { name: "backup", groups: "www-data", shell: "/bin/sh" }

# Loop dengan register
- name: Check multiple services
  command: systemctl is-active {{ item }}
  loop:
    - nginx
    - mysql
    - redis
  register: service_results
  ignore_errors: yes

- name: Show failed services
  debug:
    msg: "{{ item.item }} is {{ item.stdout }}"
  loop: "{{ service_results.results }}"
  when: item.rc != 0

# Membuat role baru dengan ansible-galaxy
ansible-galaxy init roles/nginx
# Hasil:
roles/nginx/
├── defaults/
│   └── main.yml          # Default variables (lowest priority)
├── files/                 # Static files
├── handlers/
│   └── main.yml          # Handlers
├── meta/
│   └── main.yml          # Metadata & dependencies
├── tasks/
│   └── main.yml          # Main tasks
├── templates/             # Jinja2 templates
├── tests/
│   ├── inventory
│   └── test.yml
├── vars/
│   └── main.yml          # Variables (higher priority)
└── README.md

# roles/nginx/defaults/main.yml
nginx_port: 80
nginx_worker_processes: "auto"
nginx_worker_connections: 1024
nginx_keepalive_timeout: 65
nginx_client_max_body_size: "16m"
nginx_server_name: "localhost"
nginx_root_dir: "/var/www/html"
nginx_enable_ssl: false
nginx_ssl_certificate: ""
nginx_ssl_certificate_key: ""

# roles/nginx/tasks/main.yml
---
- name: Install Nginx
  apt:
    name: nginx
    state: present
    update_cache: yes
  tags: install

- name: Remove default config
  file:
    path: /etc/nginx/sites-enabled/default
    state: absent
  tags: config

- name: Copy Nginx configuration
  template:
    src: nginx.conf.j2
    dest: /etc/nginx/nginx.conf
    owner: root
    group: root
    mode: '0644'
  notify: Restart Nginx
  tags: config

- name: Copy site configuration
  template:
    src: site.conf.j2
    dest: /etc/nginx/sites-available/{{ nginx_server_name }}.conf
    owner: root
    group: root
    mode: '0644'
  notify: Reload Nginx
  tags: config

- name: Enable site
  file:
    src: /etc/nginx/sites-available/{{ nginx_server_name }}.conf
    dest: /etc/nginx/sites-enabled/{{ nginx_server_name }}.conf
    state: link
  notify: Reload Nginx
  tags: config

- name: Ensure Nginx is running
  service:
    name: nginx
    state: started
    enabled: yes
  tags: service

# roles/nginx/handlers/main.yml
---
- name: Restart Nginx
  service:
    name: nginx
    state: restarted

- name: Reload Nginx
  service:
    name: nginx
    state: reloaded

# playbooks/site.yaml
---
- name: Configure Web Servers
  hosts: webservers
  become: yes
  roles:
    - role: common         # Role dasar (selalu dipakai)
    - role: nginx           # Role Nginx
      vars:
        nginx_port: 80
        nginx_server_name: "app.example.com"
        nginx_enable_ssl: true
    - role: app             # Role aplikasi custom
      tags: app

- name: Configure Database Servers
  hosts: dbservers
  become: yes
  roles:
    - role: common
    - role: mysql
      vars:
        mysql_port: 3306
    - role: monitoring

# Cari role di Galaxy
ansible-galaxy search nginx

# Install role
ansible-galaxy install geerlingguy.nginx
ansible-galaxy install geerlingguy.mysql
ansible-galaxy install geerlingguy.redis

# Install collection
ansible-galaxy collection install community.general
ansible-galaxy collection install community.docker

# Install dari requirements file
ansible-galaxy install -r requirements.yml

# List installed roles
ansible-galaxy list

# templates/nginx.conf.j2
# Managed by Ansible — jangan edit manual!
# Generated: {{ ansible_date_time.iso8601 }}

worker_processes {{ nginx_worker_processes }};

events {
    worker_connections {{ nginx_worker_connections }};
}

http {
    include       mime.types;
    default_type  application/octet-stream;
    sendfile      on;
    keepalive_timeout {{ nginx_keepalive_timeout }};

    # Logging
    log_format main '$remote_addr - $remote_user [$time_local] '
                    '"$request" $status $body_bytes_sent '
                    '"$http_referer" "$http_user_agent"';

    access_log /var/log/nginx/access.log main;
    error_log  /var/log/nginx/error.log warn;

    # Gzip
    gzip on;
    gzip_types text/plain text/css application/json application/javascript;

    server {
        listen {{ nginx_port }};
        server_name {{ nginx_server_name }};
        root {{ nginx_root_dir }};
        client_max_body_size {{ nginx_client_max_body_size }};

{% if nginx_enable_ssl %}
        listen 443 ssl http2;
        ssl_certificate {{ nginx_ssl_certificate }};
        ssl_certificate_key {{ nginx_ssl_certificate_key }};
        ssl_protocols TLSv1.2 TLSv1.3;
{% endif %}

        location / {
            try_files $uri $uri/ /index.html;
        }

        location /api {
            proxy_pass http://127.0.0.1:{{ app_port }};
            proxy_set_header Host $host;
            proxy_set_header X-Real-IP $remote_addr;
        }

{% for server in upstream_servers %}
        upstream backend_{{ server.name }} {
            server {{ server.address }}:{{ server.port }};
        }
{% endfor %}
    }
}

# templates/hosts.j2
# Managed by Ansible
127.0.0.1   localhost
{% for host in groups['webservers'] %}
{{ hostvars[host]['ansible_default_ipv4']['address'] }}  {{ host }}
{% endfor %}
{% for host in groups['dbservers'] %}
{{ hostvars[host]['ansible_default_ipv4']['address'] }}  {{ host }}
{% endfor %}

# Buat encrypted file
ansible-vault create secrets.yml

# Edit encrypted file
ansible-vault edit secrets.yml

# Encrypt file yang sudah ada
ansible-vault encrypt group_vars/production/secrets.yml

# Decrypt file
ansible-vault decrypt secrets.yml

# View encrypted file (tanpa decrypt)
ansible-vault view secrets.yml

# Change vault password
ansible-vault rekey secrets.yml

# Jalankan playbook dengan vault password
ansible-playbook site.yml --ask-vault-pass

# Jalankan dengan vault password file
ansible-playbook site.yml --vault-password-file ~/.vault_pass

# group_vars/production/secrets.yml (encrypted)
$ANSIBLE_VAULT;1.1;AES256
38326665383036346463356266363964323531306363656238393539383232323838376537656439
...

# Referensi di playbook
- name: Configure database
  mysql_user:
    name: "{{ app_db_user }}"
    password: "{{ vault_db_password }}"  # Disimpan di file terenkripsi
    priv: "{{ app_db_name }}.*:ALL"

ansible-project/
├── ansible.cfg              # Ansible configuration
├── inventory/
│   ├── production/
│   │   ├── hosts.yaml       # Production hosts
│   │   ├── group_vars/
│   │   │   ├── all.yaml
│   │   │   ├── webservers.yaml
│   │   │   └── dbservers.yaml
│   │   └── host_vars/
│   │       └── web1.yaml
│   └── staging/
│       ├── hosts.yaml
│       └── group_vars/
├── roles/
│   ├── common/
│   ├── nginx/
│   ├── mysql/
│   └── app/
├── playbooks/
│   ├── site.yaml            # Main playbook
│   ├── webservers.yaml
│   ├── dbservers.yaml
│   └── deploy.yaml
├── templates/
├── files/
├── requirements.yml         # Galaxy dependencies
└── README.md
