Apache Airflow untuk Data Pipeline — DAGs, Operators, XCom & Monitoring

# Instalasi Airflow dengan pip
# (gunakan constraint untuk versi yang kompatibel)

AIRFLOW_VERSION=2.9.3
PYTHON_VERSION="$(python --version | cut -d " " -f 2 | cut -d "." -f 1-2)"
CONSTRAINT_URL="https://raw.githubusercontent.com/apache/airflow/constraints-${AIRFLOW_VERSION}/constraints-${PYTHON_VERSION}.txt"

pip install "apache-airflow==${AIRFLOW_VERSION}" --constraint "${CONSTRAINT_URL}"

# Install providers yang umum
pip install apache-airflow-providers-google
pip install apache-airflow-providers-amazon
pip install apache-airflow-providers-postgres

# Inisialisasi database
airflow db migrate

# Buat user admin
airflow users create \
  --username admin \
  --firstname Admin \
  --lastname User \
  --role Admin \
  --email admin@beebane.com \
  --password admin123

# Jalankan webserver dan scheduler
airflow webserver --port 8080 &
airflow scheduler &

# Buka http://localhost:8080

# Atau gunakan Docker (recommended)
# curl -LfO 'https://airflow.apache.org/docs/apache-airflow/stable/docker-compose.yaml'
# docker compose up -d

# =============================================
# File: dags/etlpipeline.py
# Simpan di ~/airflow/dags/
# =============================================
from datetime import datetime, timedelta
from airflow import DAG
from airflow.operators.python import PythonOperator
from airflow.operators.bash import BashOperator

# Default args untuk semua task dalam DAG
default_args = {
    "owner": "beebane",
    "depends_on_past": False,
    "email": ["alert@beebane.com"],
    "email_on_failure": True,
    "email_on_retry": False,
    "retries": 2,
    "retry_delay": timedelta(minutes=5),
}

# Definisikan DAG
dag = DAG(
    dag_id="etl_penjualan_harian",
    default_args=default_args,
    description="ETL pipeline untuk data penjualan harian",
    schedule="0 6 * * *",       # Setiap hari jam 6 pagi
    start_date=datetime(2026, 1, 1),
    catchup=False,              # Jangan backfill otomatis
    tags=["etl", "penjualan", "production"],
    max_active_runs=1,          # Hanya 1 run aktif
)

# ----- Definisikan Tasks -----
def extract_data(**context):
    """Extract data dari sumber."""
    import pandas as pd
    df = pd.read_csv("data/penjualan_raw.csv")
    print(f"Extracted {len(df)} records")
    # Simpan ke temporary
    df.to_csv("/tmp/extracted.csv", index=False)
    return len(df)

def transform_data(**context):
    """Transform dan bersihkan data."""
    import pandas as pd
    df = pd.read_csv("/tmp/extracted.csv")

    # Cleaning
    df = df.dropna()
    df["total"] = df["harga"] * df["jumlah"]
    df["tanggal"] = pd.to_datetime(df["tanggal"])

    df.to_csv("/tmp/transformed.csv", index=False)
    print(f"Transformed: {len(df)} clean records")

def load_data(**context):
    """Load ke database tujuan."""
    import pandas as pd
    df = pd.read_csv("/tmp/transformed.csv")
    # df.to_sql("penjualan", engine, if_exists="append")
    print(f"Loaded {len(df)} records to database")

# Task definitions
task_extract = PythonOperator(
    task_id="extract",
    python_callable=extract_data,
    dag=dag,
)

task_transform = PythonOperator(
    task_id="transform",
    python_callable=transform_data,
    dag=dag,
)

task_load = PythonOperator(
    task_id="load",
    python_callable=load_data,
    dag=dag,
)

task_notify = BashOperator(
    task_id="notify",
    bash_command='echo "ETL pipeline selesai pada $(date)"',
    dag=dag,
)

# ----- Dependencies -----
# Setelah extract → transform → load → notify
task_extract >> task_transform >> task_load >> task_notify
# Atau: task_extract.set_downstream(task_transform)

# =============================================
# Operator Examples
# =============================================
from airflow.operators.python import PythonOperator, BranchPythonOperator
from airflow.operators.bash import BashOperator
from airflow.operators.email import EmailOperator
from airflow.providers.postgres.operators.postgres import PostgresOperator
from airflow.operators.empty import EmptyOperator

# PythonOperator
def process_data(**context):
    ti = context["ti"]
    data = ti.xcom_pull(task_ids="extract")
    processed = [x * 2 for x in data]
    return processed

task_process = PythonOperator(
    task_id="process",
    python_callable=process_data,
    dag=dag,
)

# PostgresOperator
task_create_table = PostgresOperator(
    task_id="create_table",
    postgres_conn_id="my_postgres",
    sql="""
        CREATE TABLE IF NOT EXISTS sales (
            id SERIAL PRIMARY KEY,
            tanggal DATE,
            total DECIMAL(10,2)
        );
    """,
    dag=dag,
)

# BranchPythonOperator (conditional)
def choose_branch(**context):
    import datetime
    if datetime.date.today().weekday() == 0:  # Monday
        return "weekly_report"
    return "daily_report"

branch = BranchPythonOperator(
    task_id="choose_branch",
    python_callable=choose_branch,
    dag=dag,
)

daily = EmptyOperator(task_id="daily_report", dag=dag)
weekly = EmptyOperator(task_id="weekly_report", dag=dag)

branch >> [daily, weekly]

# =============================================
# XCom — Task Communication
# =============================================

# Push data: return value otomatis menjadi XCom
def extract(**context):
    data = {"records": 1500, "date": "2026-06-29"}
    return data  # Otomatis push ke XCom

# Pull data
def transform(**context):
    ti = context["ti"]
    data = ti.xcom_pull(task_ids="extract", key="return_value")
    print(f"Received {data['records']} records")

    # Push hasil transform
    ti.xcom_push(key="transform_result", value={"clean_records": 1450})

# Manual XCom push
def load(**context):
    ti = context["ti"]
    result = ti.xcom_pull(task_ids="transform", key="transform_result")
    print(f"Loading {result['clean_records']} records")

# ⚠️ XCom bukan untuk data besar! Max ~48KB (default)
# Untuk data besar: simpan ke file/S3, pass path via XCom
def extract_large(**context):
    df = pd.read_csv("large_file.csv")
    path = "/tmp/extracted.parquet"
    df.to_parquet(path)
    return path  # Hanya pass path file

# =============================================
# Sensors
# =============================================
from airflow.sensors.filesystem import FileSensor
from airflow.sensors.external_task import ExternalTaskSensor
from airflow.sensors.sql import SqlSensor
from airflow.sensors.python import PythonSensor

# FileSensor: tunggu file muncul
wait_for_file = FileSensor(
    task_id="wait_for_data_file",
    filepath="/data/incoming/sales_{{ ds }}.csv",
    fs_type="local",
    poke_interval=30,   # Cek setiap 30 detik
    timeout=3600,       # Timeout 1 jam
    mode="reschedule",  # Release worker slot saat menunggu
    dag=dag,
)

# ExternalTaskSensor: tunggu task lain selesai
wait_for_other_dag = ExternalTaskSensor(
    task_id="wait_for_extract_dag",
    external_dag_id="extract_pipeline",
    external_task_id="load",
    timeout=7200,
    dag=dag,
)

# PythonSensor: custom condition
def check_api_available():
    import requests
    try:
        r = requests.get("https://api.example.com/health", timeout=5)
        return r.status_code == 200
    except:
        return False

wait_for_api = PythonSensor(
    task_id="wait_for_api",
    python_callable=check_api_available,
    poke_interval=60,
    timeout=1800,
    dag=dag,
)

# =============================================
# Pools & Priority
# =============================================

# Pool: batasi concurrent tasks ke resource tertentu
# Buat pool via CLI:
# airflow pools set db_pool 5 "Pool untuk database tasks"

task_db = PythonOperator(
    task_id="db_operation",
    python_callable=my_func,
    pool="db_pool",         # Batasi ke pool ini
    pool_slots=1,           # Gunakan 1 slot
    priority_weight=10,     # Prioritas lebih tinggi
    dag=dag,
)

# DAG-level concurrency settings
dag = DAG(
    "my_dag",
    max_active_runs=2,              # Max 2 run bersamaan
    max_active_tasks=10,            # Max 10 task bersamaan
    concurrency=5,                  # Max 5 task dalam 1 DAG run
)

# Task-level settings
task = PythonOperator(
    task_id="heavy_task",
    python_callable=heavy_func,
    retries=3,
    retry_delay=timedelta(minutes=10),
    execution_timeout=timedelta(hours=1),
    queue="heavy",                  # Worker queue
    dag=dag,
)

# =============================================
# Backfill & Catchup
# =============================================

# Backfill: jalankan DAG untuk rentang tanggal tertentu
airflow dags backfill \
  -s 2026-01-01 \
  -e 2026-06-01 \
  etl_penjualan_harian

# Catchup: otomatis jalankan semua run yang terlewat
# Diatur di DAG:
dag = DAG(
    "my_dag",
    start_date=datetime(2026, 1, 1),
    catchup=True,    # Jalankan semua dari start_date
)

# Disable catchup untuk production:
dag = DAG(
    "my_dag",
    start_date=datetime(2026, 1, 1),
    catchup=False,   # Hanya jalankan yang terbaru
)
